/ / / / / / / КАПОТ, БЕЗ PRE-CREANER, КАПОТ (/)
Запчасти Komatsu PC228USLC-8 КАПОТ, БЕЗ PRE-CREANER, КАПОТ (/) КАПОТ, БЕЗ PRE-CREANER
48
49
46
47
43
44
16
17
16
17
21
22
41
42
45
12
14
13
15
15
18
19
20
24
25
23
38
39
26
29
32
35
37
27
28
30
31
36
33
34
40
10
11
4
5
6
1
7
7
2
8
9
3
3
51
50
52
53
1
22U-54-32213
Hood
|$1
22U-54-32212
Hood
|$2
22U-54-32211
Hood
2
22U-54-32221
Seal
3
22U-54-32480
Sheet
4
22B-54-21150
Hinge
5
01010-81230
Bolt
6
01643-31232
Washer
7
22B-46-24361
Lock Assembly
8
22B-46-24180
Spring
9
01023-10508
Screw
10
01010-81230
Bolt
11
01643-31232
Washer
|$13
22U-54-32301
Frame Assembly
12
Frame
13
22U-54-32331
Sheet
14
22U-54-32341
Seal
15
20Y-54-27182
Bracket
16
01010-81230
Bolt
17
01643-31232
Washer
18
205-54-68440
Plate
19
01224-40625
Screw, Philips Head
20
22U-54-32350
Bracket
21
01010-81230
Bolt
22
01643-31232
Washer
23
22U-54-32360
Bracket
24
01010-81230
Bolt
25
01643-31232
Washer
26
22U-54-32460
Cover
27
01010-81230
Bolt
28
01643-31232
Washer
29
22U-54-32590
Bracket
30
01010-81230
Bolt
31
01643-31232
Washer
32
22U-54-32371
Bracket
33
01010-81230
Bolt
34
01643-31232
Washer
35
22U-54-32440
Bar
36
01643-31032
Washer
37
04050-13018
Pin
38
20B-54-12210
Spring
39
01023-10408
Screw
40
22U-54-32450
Plate
41
01010-81240
Bolt
42
01643-31232
Washer
43
01010-81230
Bolt
44
01643-31232
Washer
45
22U-54-32381
Bracket
46
01010-81230
Bolt
47
01643-31232
Washer
48
22U-54-32392
Bracket
|$51
22U-54-32391
Bracket
49
22U-54-32610
Collar
50
01643-31645
Washer
51
01010-81685
Bolt
52
01010-81230
Bolt
53
175-54-34170
Washer
|$57
01643-31232
Washer
