Запчасти Komatsu PC240LC-10 РУКОЯТЬ, MM, РУКОЯТЬ РУКОЯТЬ, MM
17
13
11
14
7
16
15
7
22
23
11
4
6
23
22
10
1
5
2
18
12
19
9
24
21
20
3
9
12
10
12
8
8
12
|$1
206-944-K425
Arm Assembly
1
206-944-K432
Arm
2
20Y-970-3570
Bracket (Welded)
3
20Y-70-K6410
Seat (Welded)
4
206-62-K2740
Bracket (Welded)
5
20Y-62-K5830
Bracket (Welded)
6
20Y-62-K7290
Seat (Welded)
7
20Y-70-31272
Bushing
8
20Y-70-32410
Bushing
9
21K-70-12161
Bushing
10
07020-00000
Fitting, Grease
11
07145-00090
Seal, Dust
12
20Y-70-23230
Seal, Dust
13
206-70-22250
Pin
14
205-70-66581
Plate
15
01010-81230
Bolt
16
01643-31232
Washer
17
21K-70-71650
Spacer, T=1.0mm
18
206-70-22260
Pin
19
205-70-66581
Plate
20
01010-81230
Bolt
21
01643-31232
Washer
22
21K-70-71650
Spacer, T=1.0mm
23
21K-70-71660
Spacer, T=2.0mm
24
707-H1-X0230
Cylinder Assembly
