Запчасти Komatsu PC240LC-8K РУКОЯТЬ (.M) (№K-K9) T РАБОЧЕЕ ОБОРУДОВАНИЕ
21
22
23
21
6
10
16
12
13
15
14
4
6
10
9
4
3
17
5
2
18
20
19
11
8
9
11
7
7
11
8
11
1
1
206-944-K423
ARM
|1
206-944-K422
ARM
2
20J-70-12180
SEAT, WELDED
3
20Y-62-K5830
BRACKET, WELDED
4
206-62-K2740
BRACKET, WELDED
5
20Y-970-3570
BRACKET, WELDED
6
20Y-70-31272
BUSHING
7
20Y-70-32410
BUSHING
8
21K-70-12161
BUSHING
9
07020-00000
FITTING, GREASE
10
07145-00090
SEAL
11
20Y-70-23230
SEAL
12
206-70-71590
PIN
13
205-70-66580
PLATE
14
01010-81230
BOLT
15
01643-31232
WASHER
16
20Y-70-31431
SPACER, 1.0MM
|16
20Y-70-31430
SPACER, 1.0MM
17
206-70-51170
PIN
18
205-70-66580
PLATE
19
01010-81230
BOLT
20
01643-31232
WASHER
21
20Y-70-31431
SPACER, 1.0MM
|21
20Y-70-31430
SPACER, 1.0MM
22
206-70-71451
SPACER, 2.0MM
|22
206-70-71450
SPACER, 2.0MM
23
707-01-XS870
CYLINDER GROUP
