/ / / / / / ЗАПРАВОЧН.LING ЛИНИЯ (№K-)
Запчасти Komatsu PC240LC-8K ЗАПРАВОЧН.LING ЛИНИЯ (№K-) W РАЗНОЕ
40
41
6
7
24
5
17
18
19
20
4
14
25
26
32
27
27
4
31
30
1
39
8
10
9
3
35
2
37
38
36
15
23
16
21
22
28
29
33
34
26
13
12
11
35
1
206-04-K1113
PUMP ASSEMBLY
|1
206-04-K1112
PUMP ASSEMBLY
2
20Y-04-K2450
VALVE ASSEMBLY
3
20Y-04-K2351
HOSE
4
206-04-K1121
HOSE
5
206-04-K1131
HOSE
6
20Y-04-K3081
SWITCH ASSEMBLY
|6
20Y-04-K4021
SWITCH
|6
20Y-04-K3094
FLANGE
|6
07002-11223
O-RING
7
07000-13032
O-RING
8
20Y-04-K4081
SWITCH BOX ASSEMBLY
9
01010-81230
BOLT
10
01643-31232
WASHER
11
01010-81225
BOLT
12
01643-31232
WASHER
13
07289-00035
CLAMP
14
07289-00035
CLAMP
15
206-04-71130
TUBE
16
04434-52512
CLIP
17
01010-81225
BOLT
18
01643-31232
WASHER
19
04434-52512
CLIP
20
198-43-15310
COLLAR, 10MM
21
01010-81235
BOLT
22
01643-31232
WASHER
23
07289-00035
CLAMP
24
07289-00035
CLAMP
25
581-04-22290
CLIP
26
581-04-22290
CLIP
27
581-04-22290
CLIP
28
01010-81225
BOLT
29
01643-31232
WASHER
30
01010-81225
BOLT
31
01643-31232
WASHER
32
198-43-15310
COLLAR, 10MM
33
01010-81235
BOLT
34
01643-31232
WASHER
35
07289-00035
CLAMP
36
20Y-04-38170
BRACKET
37
01010-81020
BOLT
38
01643-31032
WASHER
39
08034-20519
BAND
40
01010-80616
BOLT
41
0164330623
WASHER
