/ / / / / / FIG NO. H- ГИДР. БАК. (С ДАТЧИКОМ)
Запчасти Komatsu PC250LC-6LC FIG NO. H- ГИДР. БАК. (С ДАТЧИКОМ) ГИДРАВЛИКА
37
43
42
40
17
41
38
18
11
35
39
15
36
33
23
16
34
24
19
30
10
29
20
31
14
28
13
21
12
31
22
32
2
3
2
26
27
25
46
47
6
1
7
9
8
5
45
44
4
|$0
20Y-60-00061
TANK ASSEMBLY, HYDRAULIC
1
20Y-60-21113
TANK, HYDRAULIC
2
208-04-19130
ELBOW
3
203-60-31160
TUBE
4
07044-12412
PLUG
5
07002-02434
O-RING
6
20Y-966-2970
TEE
7
07002-02434
O-RING
8
07236-10628
ELBOW
9
07002-02434
O-RING
10
20Y-60-21211
CASE
11
07063-01210
ELEMENT, HYDRAULIC TANK
12
206-60-41221
STRAINER, HYDRAULIC TANK
13
12R-60-11300
VALVE ASSEMBLY
14
20Y-60-21240
SPRING
15
20Y-60-21250
COVER
16
07000-05165
O-RING
17
01010-51240
BOLT
18
01643-31232
WASHER
19
20Y-60-21220
HEAD
20
07000-05210
O-RING
21
20Y-60-21230
RING
22
20Y-60-21260
PACKING
23
01010-51240
BOLT
24
01643-31232
WASHER
25
7861-92-4210
SENSOR
26
01252-40612
BOLT
27
01641-20608
WASHER
|$28
20Y-60-21301
STRAINER ASSEMBLY
28
20Y-60-21330
ROD ASSEMBLY
29
20Y-60-21320
HOLDER
30
12R-60-11230
SPRING
31
01580-11008
NUT
32
20Y-60-21311
STRAINER, HYDRAULIC TANK
33
NSS
COVER
34
07000-05180
O-RING
35
01010-51225
BOLT
36
01643-31232
WASHER
37
20Y-60-21440
CAP
38
20Y-60-21460
NECK
39
205-60-51460
GASKET
40
01220-40516
SCREW
41
01601-20513
WASHER
42
07285-00155
CLIP
43
07270-61509
TUBE
44
01010-51635
BOLT
45
01643-31645
WASHER
46
209-62-57210
TEE
47
07002-02034
O-RING
