/ / / / / / H8-A ГИДРОЛИНИЯ ОСНОВН. ЛИНИЯ PPC ПАТРУБКИ
Запчасти Komatsu PC270LC-8 H8-A ГИДРОЛИНИЯ ОСНОВН. ЛИНИЯ PPC ПАТРУБКИ ГИДРАВЛИКА
21
4
22
7
19
1
1
2
4
2
7
5
3
8
3
8
5
17
6
12
6
14
13
11
16
15
17
10
12
9
14
20
13
18
15
11
25
9
24
23
1
08034-20536
BAND
2
208-62-72160
HOSE, L = 720 MM
3
20Y-62-51160
HOSE, L = 750 MM
4
20Y-62-51870
HOSE, L = 700 MM
5
20Y-62-51890
HOSE, L = 900 MM
6
20Y-62-22820
BAND, BLUE
7
20Y-62-22830
BAND, WHITE
8
20Y-62-22860
BAND, BROWN
9
08034-20536
BAND
10
208-62-72310
HOSE, L = 950 MM
11
208-62-72590
HOSE, L = 700 MM
12
20Y-62-51880
HOSE, L = 1100 MM
13
20Y-62-51890
HOSE, L = 900 MM
14
20Y-62-22790
BAND, RED
15
20Y-62-22810
BAND, YELLOW
16
20Y-62-22840
BAND, BLACK
17
20Y-62-22850
BAND, GREEN
18
20Y-62-51910
HOSE, L = 400 MM
19
04434-53212
CLIP
20
04434-52712
CLIP
21
01010-81225
BOLT
22
01643-31232
WASHER
23
01010-81225
BOLT
24
01643-31232
WASHER
25
08034-20536
BAND
