/ / / / / / РУКОЯТЬ (/) (.M) (№K-K99)
Запчасти Komatsu PC290LC-8K РУКОЯТЬ (/) (.M) (№K-K99) T РАБОЧЕЕ ОБОРУДОВАНИЕ
16
10
12
6
13
15
14
6
10
9
21
22
2
21
17
1
18
5
20
11
19
8
23
3
4
8
11
9
11
7
7
11
|1
206-70-K2380
Arm Assembly
1
206-70-K8020
Arm
2
20Y-70-42E51
Seat
3
20Y-970-3570
Bracket
4
20J-70-12180
Seat, Welded
5
206-62-K2740
Bracket, Welded
6
20Y-70-31272
Bushing
7
20Y-70-32410
Bushing
8
21K-70-12161
Bushing
9
07020-00000
Fitting, Grease
10
07145-00090
Seal
11
20Y-70-23230
Seal
12
206-70-71340
Pin
13
205-70-66580
Plate
14
01010-81230
Bolt
15
01643-31232
Washer
16
20Y-70-31431
Spacer, T=1.0mm
17
206-70-71350
Pin
18
205-70-66580
Plate
19
01010-81230
Bolt
20
01643-31232
Washer
21
20Y-70-31431
Spacer, T=1.0mm
22
206-70-71451
Spacer, T=2.0mm
23
707-01-XR930
Cylinder Group
