Запчасти Komatsu PC300HD-7L T-A ЦИЛИНДР СТРЕЛЫ РАБОЧЕЕ ОБОРУДОВАНИЕ
10
11
10
9
20
19
43
16
44
42
18
41
13
17
14
15
36
35
6
32
31
22
21
33
3
5
8
2
1
3
7
8
4
37
27
34
26
24
38
23
25
39
40
26
27
28
29
30
33
28
12
32
|$0
707-01-0A430
CYLINDER ASSEMBLY
1
707-13-14580
CYLINDER
2
707-76-90490
BUSHING
3
07145-00090
SEAL, DUST
4
07020-00000
FITTING, GREASE
5
07043-00108
PLUG
6
707-58-10720
ROD
7
707-76-10290
BUSHING
8
07145-00100
SEAL, DUST
9
707-71-34800
COLLAR
10
707-35-91420
RING, BACK-UP
11
07000-15130
O-RING
12
707-71-61090
PLUNGER
13
707-27-14930
HEAD
14
176-63-56170
SEAL, DUST
15
07179-13114
RING, SNAP
16
707-52-90780
BUSHING
17
707-51-10030
PACKING, ROD
18
707-51-10640
RING, BUFFER
19
707-35-91420
RING, BACK-UP
20
07000-15130
O-RING
21
01010-81875
BOLT
22
707-41-11840
WASHER
23
707-36-14650
PISTON
24
01310-01216
SCREW
25
707-44-14180
RING, PISTON
26
707-39-14110
RING, WEAR
27
707-44-14910
RING
28
07001-05090
RING, BACK-UP
29
07000-15090
O-RING
30
707-86-11580
TUBE, LEFT HAND
|$31
707-86-11590
TUBE, RIGHT HAND
31
207-63-54580
TUBE, LEFT HAND
|$33
207-63-54680
TUBE, RIGHT HAND
32
01435-01055
BOLT
33
07000-13035
O-RING
34
207-63-54590
BRACKET
35
707-88-21370
BAND
36
01435-01235
BOLT
37
07283-23442
CLIP
38
01643-31032
WASHER
39
01599-01011
NUT
40
01435-01025
BOLT
41
707-88-33040
CAP
42
07371-31049
FLANGE, SPLIT
43
07372-21035
BOLT
44
01643-51032
WASHER
