CRANKING МОТОР - 7. KW

Запчасти Komatsu PC300LC-5 CRANKING МОТОР - 7. KW ЭЛЕКТРИКА

Схема запчастей Komatsu PC300LC-5 - CRANKING МОТОР - 7. KW ЭЛЕКТРИКА
27
18
37
21
20
19
30
38
39
32
31
9
29
34
10
30
35
28
11
22
36
23
24
25
6
8
33
2
15
14
5
12
7
13
4
3
1
4
26
16
17
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$0

600-813-6510

MOTOR ASSEMBLY, CRANKING - 7.5 KW

1

SD1310-08100X0

YOKE ASSEMBLY

2

SD2660-07100X9

BRUSH

3

SD2660-07100X8

BRUSH

4

SD4141-23800X0

PACKING

5

SD2240-22650X0

BRACKET, REAR

6

SD1331-03900X0

BRUSH HOLDER ASSEMBLY

7

SD2660-07000X9

BRUSH

8

SD5250-02600X0

SPRING, BRUSH

9

SD5000-10500X0

SCREW

10

SD6414-04510X0

O-RING

11

SD3040-12100X0

PLATE

12

SD1320-07500X0

ARMATURE ASSEMBLY

13

SD6206-01140X0

BEARING

14

SD6206-01130X0

BEARING

15

SD5010-31720X0

BOLT

16

SD2245-00720X0

CASE, GEAR

17

SD5031-05700X0

SHIM

18

SD2441-03400X0

SHAFT

19

SD2244-07100X0

HOLDER, CENTER

20

SD6410-01930X0

SEAL, OIL

21

SD6206-01700X0

BEARING

22

SD1361-05800X0

PINION

23

SD3661-01900X0

STOPPER, PINION

24

SD5221-01000X0

HOOK

25

SD5058-04100X0

RING, RETAINING

26

SD5010-31710X0

BOLT

27

SD4141-23700X0

PACKING

27

SD4141-23701X0

PACKING

28

SD1372-04000X0

LEVER

29

SD3600-17800X0

ROD

30

SD4223-03700X0

HOLDER

31

SD5201-09300X0

SPRING, COIL

32

SD2407-02101X0

COLLAR

33

SD2244-07010X0

BRACKET, CENTER

34

SD6414-04650X0

O-RING

35

SD2046-14500X9

CASE ASSEMBLY, PINION

36

SD2620-09600X9

BEARING

37

SD1350-10220X9

SWITCH, CRANKING MOTOR SOLENOID

38

SD5010-27300X0

BOLT

39

SD0590-0012113

RELAY, SAFETY
