Запчасти Komatsu PC300LC-5 МЕХАНИЗМ ПОВОРОТА МЕХ-М ОТБОРА МОЩНОСТИ И ПОВОРОТН.

|$0

207-26-00100

MACHINERY ASSEMBLY, SWING

1

207-26-54241

SHAFT

2

07012-00140

SEAL

3

207-26-54261

COVER

|$4

01010-81040

BOLT

|$5

01643-31032

WASHER

4

06000-22324

BEARING

5

207-26-54251

SPACER

6

207-26-54131

CASE, SWING MACHINERY

|$9

01010-82480

BOLT

|$10

01643-32460

WASHER

7

06000-22222

BEARING

8

207-26-54190

HOLDER

9

207-26-54160

GEAR, PLANETARY

10

207-26-54170

BEARING

11

207-26-54180

PIN

12

01011-51405

BOLT

13

207-26-54220

CARRIER

14

207-26-54230

PLATE

15

205-32-51210

BOLT

16

207-26-54210

GEAR, RING

17

207-26-54121

BASE, SWING MACHINERY

|$22

01010-81605

BOLT

|$23

01643-31645

WASHER

18

207-26-54280

GEAR, SUN

19

06002-32919

BEARING

20

207-26-54151

GEAR

21

04020-01228

PIN, DOWEL

22

07049-01620

PLUG

23

207-26-54111

COVER

|$30

01010-81660

BOLT

|$31

01643-31645

WASHER

24

06002-30214

BEARING

25

207-26-54141

GEAR

26

207-26-54290

CAGE

|$35

01010-81035

BOLT

|$36

01643-31032

WASHER

27

07000-05175

O-RING

28

207-26-00110

SHIM KIT

|$39

207-26-54320

SHIM - 0.4 IN. (11 MM)

|$40

207-26-54330

SHIM - 0.5 IN. (13 MM)

|$41

207-26-54340

SHIM - 0.6 IN. (16 MM)

|$42

207-26-54350

SHIM - 0.7 IN. (19 MM)

|$43

207-26-54360

SHIM - 0.8 IN. (22 MM)

29

207-26-00120

SHIM KIT

|$45

207-26-54370

SHIM - 0.4 IN. (11 MM)

|$46

207-26-54380

SHIM - 0.5 IN. (13 MM)

|$47

207-26-54390

SHIM - 0.6 IN. (16 MM)

|$48

207-26-54410

SHIM - 0.7 IN. (19 MM)

|$49

207-26-54420

SHIM - 0.8 IN. (22 MM)

30

07000-05145

O-RING

31

207-26-54310

CAGE

|$52

01010-81035

BOLT

|$53

01643-31032

WASHER

32

07049-01012

PLUG

33

07042-30108

PLUG
