/ / / / / 3-Я СТРЕЛА В СБОРЕ (№K8-K7)
Запчасти Komatsu PC350LC 3-Я СТРЕЛА В СБОРЕ (№K8-K7)
101
153
147
100
111
109
99
43
42
41
92
93
94
95
55
54
51
50
47
46
88
89
90
91
53
52
69
68
67
84
83
82
81
49
48
85
86
87
70
76
75
74
73
72
71
45
44
37
36
35
40
39
38
77
78
79
80
98
97
96
66
65
145
150
146
56
57
143
151
58
144
152
59
104
142
159
160
2
148
3
162
161
1
149
4
158
157
154
5
6
63
60
64
156
155
9
130
8
131
7
132
27
103
28
10
29
32
31
102
30
139
138
140
141
11
22
105
16
12
23
17
13
24
14
25
15
26
136
137
133
134
33
34
135
18
19
20
21
168
169
129
170
163
171
164
172
165
166
167
62
61
128
117
127
126
125
116
108
107
106
124
123
122
121
118
119
120
112
110
113
114
115
1
207-70-KG321
BOOM
|1
207-70-KG320
BOOM
2
07085-21013
HOSE
3
07000-13032
O-RING
4
07371-31049
FLANGE
5
07372-21035
BOLT
6
01643-51032
WASHER
7
208-62-85980
TUBE
8
07000-13029
O-RING
9
07000-13032
O-RING
10
208-62-86130
VALVE
11
207-62-KG370
TUBE
12
07000-13029
O-RING
13
07371-31049
FLANGE
14
07372-21035
BOLT
15
01643-51032
WASHER
16
07085-21016
HOSE
17
07000-13032
O-RING
18
207-62-KG340
TUBE
19
07000-13035
O-RING
20
01010-81045
BOLT
21
01643-31032
WASHER
22
207-62-KG360
TUBE
23
07000-13029
O-RING
24
07371-31049
FLANGE
25
07372-21035
BOLT
26
01643-51032
WASHER
27
207-62-KG420
TUBE
28
07371-31049
FLANGE
29
07372-21035
BOLT
30
01643-51032
WASHER
31
07000-13032
O-RING
32
07085-21016
HOSE
33
207-62-KG351
TUBE
|33
207-62-KG350
TUBE
34
07000-13022
O-RING
35
01010-81260
BOLT
36
01643-31232
WASHER
37
207-62-88981
CLAMP
38
207-62-88950
CLAMP
39
01010-81250
BOLT
40
01643-31232
WASHER
41
207-62-88960
CLAMP
42
01010-81250
BOLT
43
01643-31232
WASHER
44
205-62-54622
SEAT
45
207-62-88891
CLAMP
46
01010-81250
BOLT
47
01643-31232
WASHER
48
07094-10417
CLAMP
49
07095-00420
CUSHION
50
01010-81290
BOLT
51
01643-31232
WASHER
52
07094-10417
CLAMP
53
07095-00420
CUSHION
54
01010-81290
BOLT
55
01643-31232
WASHER
56
207-62-KG220
FLANGE
57
07371-31049
FLANGE
58
07372-21035
BOLT
59
01643-51032
WASHER
60
02758-00529
HOSE
61
02753-00448
HOSE
62
02753-00448
HOSE
63
02753-00439
HOSE
64
02758-00531
HOSE
65
07040-12012
PLUG
66
07002-12034
O-RING
67
02781-00422
UNION
68
07002-12034
O-RING
69
02896-11009
O-RING
70
198-33-12380
SPACER
71
20Y-62-19330
ELBOW
72
01010-81275
BOLT
73
01643-31232
WASHER
74
02781-00422
UNION
75
07002-12034
O-RING
76
02896-11012
O RING
77
207-62-88880
CLAMP
78
01010-81250
BOLT
79
01643-31232
WASHER
80
208-62-85780
CUSHION
81
207-62-88921
CLAMP
82
01010-81250
BOLT
83
01643-31232
WASHER
84
205-62-54622
SEAT
85
02781-00422
UNION
86
07002-12034
O-RING
87
02896-11009
O-RING
88
KV-B240-8080
BLOCK
89
01011-81215
BOLT
90
01011-81230
BOLT
91
01643-31232
WASHER
92
207-62-88690
CLAMP
93
01010-81250
BOLT
94
01643-31232
WASHER
95
208-62-85780
CUSHION
96
11Y-62-12630
ELBOW
97
07002-12034
O-RING
98
02896-11012
O RING
99
02896-11009
O-RING
100
07002-12034
O-RING
101
02781-10311
UNION
102
02753-00417
HOSE
103
02754-00317
HOSE
104
KV-1B52-1131
BUSHING
105
KV-B230-6190
BUSHING
106
02781-00422
UNION
107
07002-12034
O-RING
108
02896-11012
O-RING
109
KV-B240-8080
BLOCK
110
198-33-12380
WASHER
111
01010-81290
BOLT
112
01643-31232
WASHER
113
02781-00422
NIPPLE
114
07002-12034
O-RING
115
02896-11012
O-RING
116
08034-20536
BAND
117
02753-00423
HOSE
118
02781-00422
NIPPLE
119
07002-12034
O-RING
120
02896-11012
O-RING
121
KV-B240-8080
BLOCK
122
198-33-12380
WASHER
123
01010-81290
BOLT
124
01643-31232
WASHER
125
02781-00315
NIPPLE
126
07002-12034
O-RING
127
02896-11009
O-RING
128
08034-20536
BAND
129
02753-00323
HOSE
130
KV-B230-1261
ROD
131
KV-C120-3140
PIN
132
KV-C120-3150
PIN
133
KV-B230-6180
PLATE
134
01010-82055
BOLT
135
01643-32060
WASHER
136
20Y-70-11410
SPACER
137
20Y-70-11420
SPACER
138
207-70-83920
PIN
139
205-70-71310
PLATE
140
01010-81240
BOLT
141
01643-31232
WASHER
142
207-70-72390
SPACER
143
207-70-83930
PIN
144
207-70-31230
PLATE
145
01010-81640
BOLT
146
01643-31645
WASHER
147
207-70-72390
SPACER
148
207-70-72420
SPACER
149
207-70-72430
SPACER
150
KV-1B52-1140
HOLDER
151
01010-82055
BOLT
152
01643-32060
WASHER
153
207-70-72370
SPACER
154
207-70-72380
SPACER
155
207-70-31190
PIN
156
205-70-66580
PLATE
157
01010-81235
BOLT
158
01643-31232
WASHER
159
207-70-72370
SPACER
160
207-70-72380
SPACER
161
207-62-KB251
TUBE
162
07000-13032
O-RING
163
07085-21015
HOSE
164
07000-13032
O-RING
165
07371-31049
FLANGE
166
07372-21035
BOLT
167
01643-51032
WASHER
168
07083-20515
HOSE
169
07000-13032
O-RING
170
07371-30500
FLANGE
171
01010-80830
BOLT
172
01643-30823
WASHER
