Запчасти Komatsu PC35R-8 ТОПЛ. НАСОС ДВИГАТЕЛЬ
75
87
51
35
31
50
36
33
86
49
38
34
15
82
37
30
89
17
32
27
16
48
55
11
47
54
18
46
45
77
76
78
87
25
26
14
4
84
39
53
79
52
10
5
40
8
92
74
93
80
83
6
7
81
85
2
9
88
1
3
\0
871070023
MOTOR, ASSY.
1
YM729211-51400
PUMP, ASSY.
2
REGULATOR, ASSY.
3
INJECTION PUMP
4
YM22190-160002
GASKET
5
YM129155-51020
STUD
6
YM129211-51040
CAMSHAFT
7
YM26716-060002
NUT
8
YM129155-51050
BEARING
9
YM129155-51060
COVER
10
YM122710-51090
KEY
11
YM129506-51100
PLUNGER W/BARREL
14
YM129155-51140
PIN
15
YM174307-51170
RETAINER, SPRING
16
YM129155-51180
SEAT, NOZZLE SPRING
17
YM124950-51190
SPRING
18
YM129155-51200
TAPPET, ASSY
25
YM129155-51270
LOCKING, TAPPET
26
YM129155-51280
O-RING
27
YM129450-51300
VALVE DELIVERY
30
YM129155-51320
SPRING
31
YM129155-51340
GUARD, DELIVERY VALVE
32
YM124550-51350
GASKET
33
YM124550-51370
O-RING
34
YM129155-51370
STOPPER
35
YM129155-51380
LOCKING (A)
36
YM129155-51390
LOCKING (B)
37
YM129155-51400
DEFLECTOR
38
YM129155-51410
CHECK BOLT
39
YM129155-51420
PLUG
40
YM129155-51450
KIT, SHIM
45
YM129155-51500
RACK
46
YM129155-51251
BUSHING
47
YM129155-51530
SPACER
48
YM129155-51540
RING, SNAP
49
YM129155-51550
PINION
50
YM122117-51560
SCREW
51
YM174307-51560
PINION
52
YM129155-51570
PLUG
53
YM129155-51580
O-RING
54
YM129155-51591
SPRING
55
YM129155-51600
KIT, SHIM
74
YM129155-51700
COVER
75
YM129155-51710
GASKET
76
YM129155-51750
COVER
77
YM129155-51760
GASKET
78
YM129155-51790
LOCKING, RACK
79
YM129156-51910
PLATE, CAUTION
80
YM129155-51930
SPACER, T=3.25
81
YM129155-51940
SPACER, T=1.5
82
YM22217-050000
SPRING WASHER
83
YM22217-060000
SPRING WASHER
84
YM22351-050010
PEG
85
YM24101-063034
BEARING
86
YM24341-000160
O-RING
87
YM26022-050102
SCREW
88
YM26022-060162
SCREW
89
YM26116-050302
SCREW
92
YM129155-52050
GASKET
93
YM129100-52200
COVER
