/ / / / / / / СОЛЕНОИДНЫЙ КЛАПАН, ТРУБЫ (№7-)
Запчасти Komatsu PC360LC-10 СОЛЕНОИДНЫЙ КЛАПАН, ТРУБЫ (№7-) СОЛЕНОИДНЫЙ КЛАПАН
9
10
11
15
16
17
18
19
20
21
22
23
34
35
36
37
38
39
40
41
42
43
44
45
46
47
37
38
40
33
44
45
46
39
41
42
22
1
2
3
4
5
6
7
8
12
13
14
24
25
26
27
28
29
30
31
32
33
48
1
01010-81090
Bolt
2
01643-31032
Washer
3
22U-60-21330
Accumulator
4
07002-12034
O-ring
5
20Y-62-22271
Elbow
6
201-60-11390
O-ring
7
20Y-62-19560
O-ring
8
07002-11423
O-ring
9
02781-0021D
Union
10
02896-11008
O-ring
11
07002-11423
O-ring
12
208-62-71750
Elbow
13
02896-11008
O-ring
14
07002-11423
O-ring
15
21W-62-42490
Elbow
16
02896-11009
O-ring
17
07002-11423
O-ring
18
11Y-62-12130
Nipple
19
02896-11008
O-ring
20
07002-11423
O-ring
21
11Y-62-12330
Tee
22
02896-11008
O-ring
23
07002-11423
O-ring
24
02781-00422
Union
25
02896-11012
O-ring
26
07002-12034
O-ring
27
20Y-62-21940
Joint
28
07002-12034
O-ring
29
02781-0031D
Nipple
30
02896-11009
O-ring
31
07002-11423
O-ring
32
08034-20536
Band
33
08034-20536
Band
34
02742-002A8
Hose
35
02742-00210
Hose
36
08034-20519
Band
37
20Y-62-22820
Band, Blue
38
02740-00325
Hose
39
02740-00326
Hose
40
08034-20519
Band
41
20Y-62-22790
Band, Red
42
20Y-62-22810
Band, Yellow
43
207-62-41522
Hose Assembly
44
02760-002A7
Hose, Face Seal Type
45
02760-00216
Hose, Face Seal Type
46
20Y-62-22860
Band, Brown
47
207-62-45910
Hose
47
02740-00209
Hose
48
02763-003A3
Hose, Face Seal Type
