/ / / / / / H8-A ГИДРОЛИНИЯ СОЛЕНОИДНЫЙ КЛАПАН ЛИНИИ
Запчасти Komatsu PC360LC-10 H8-A ГИДРОЛИНИЯ СОЛЕНОИДНЫЙ КЛАПАН ЛИНИИ ГИДРАВЛИКА
1
2
3
4
5
6
7
8
18
19
20
15
16
17
34
35
36
37
37
21
22
23
44
45
46
47
9
10
11
33
43
38
39
40
41
42
44
45
46
24
25
26
27
28
29
30
31
32
33
48
38
39
40
41
42
12
13
14
1
01010-81090
BOLT
2
01643-31032
WASHER
3
20Y-60-A1221
ACCUMULATOR
4
07002-12034
O-RING
5
20Y-62-22271
ELBOW
6
201-60-11390
O-RING
7
20Y-62-19560
O-RING
8
07002-11423
O-RING
9
02781-0021D
UNION
10
02896-11008
O-RING
11
07002-11423
O-RING
12
208-62-71750
ELBOW
13
02896-11008
O-RING
14
07002-11423
O-RING
15
21W-62-42490
ELBOW
16
02896-11009
O-RING
17
07002-11423
O-RING
18
11Y-62-12130
NIPPLE
19
02896-11008
O-RING
20
07002-11423
O-RING
21
11Y-62-12330
TEE
22
02896-11008
O-RING
23
07002-11423
O-RING
24
02781-00422
UNION
25
02896-11012
O-RING
26
07002-12034
O-RING
27
20Y-62-21940
FILTER ASSEMBLY
28
07002-12034
O-RING
29
02781-0031D
UNION
30
02896-11009
O-RING
31
07002-11423
O-RING
32
08034-20536
STRAP, TIE
33
08034-20536
STRAP, TIE
34
02742-002A8
HOSE
35
02742-00210
HOSE
36
08034-20519
STRAP, TIE
37
20Y-62-22820
BAND, BLUE
38
02740-00325
HOSE
39
02740-00326
HOSE
40
08034-20519
STRAP, TIE
41
20Y-62-22790
BAND, RED
42
20Y-62-22810
BAND, YELLOW
43
207-62-41522
HOSE ASSEMBLY
44
02760-002A7
HOSE, FACE SEAL TYPE
45
02760-00216
HOSE, FACE SEAL TYPE
46
20Y-62-22860
BAND, BROWN
47
207-62-45910
HOSE
48
02763-003A3
HOSE, FACE SEAL TYPE
