/ / / / / / / ANTI-DROP КЛАПАН, СТРЕЛА И РУКОЯТЬ, ШАССИ ТРУБЫ
Запчасти Komatsu PC360NLC-10 ANTI-DROP КЛАПАН, СТРЕЛА И РУКОЯТЬ, ШАССИ ТРУБЫ ANTI-DROP КЛАПАН, СТРЕЛА И РУКОЯТЬ
35
37
9
7
8
11
10
12
2
3
39
38
40
42
41
36
1
65
6
8
7
9
64
66
13
15
14
21
22
24
23
25
26
27
25
26
27
29
30
28
33
34
31
32
58
59
56
53
5
4
48
49
47
46
45
43
44
53
52
45
50
51
61
62
61
51
52
57
55
54
54
55
60
17
16
18
20
19
63
1
207-62-45540
Block
2
01010-81280
Bolt
3
01643-31232
Washer
4
01011-81220
Bolt
5
01643-31232
Washer
6
142-03-11160
Spacer
7
02783-10522
Elbow
8
07002-12434
O-Ring
9
02896-11015
O-Ring
10
02782-10522
Elbow
11
07002-12434
O-Ring
12
02896-11015
O-Ring
13
02783-10522
Elbow
14
07002-12434
O-Ring
15
02896-11015
O-Ring
16
201-62-71810
Joint
17
07002-12434
O-Ring
18
02783-10522
Elbow
19
07002-12434
O-Ring
20
02896-11015
O-Ring
21
20Y-62-19330
Elbow
22
142-03-11160
Spacer
23
01010-81260
Bolt
24
01643-31232
Washer
25
02782-10315
Elbow
26
07002-12034
O-Ring
27
02896-11009
O-Ring
28
02783-10315
Elbow
29
07002-12034
O-Ring
30
02896-11009
O-Ring
31
207-62-73530
Elbow
32
142-03-11160
Spacer
33
01010-81260
Bolt
34
01643-31232
Washer
35
02783-10315
Elbow
36
07002-12034
O-Ring
37
02896-11009
O-Ring
38
02782-10315
Elbow
39
07002-12034
O-Ring
40
02896-11009
O-Ring
41
7861-93-1812
Sensor, Pressure
42
07002-61823
O-Ring
43
21N-64-36680
Tee
44
07002-11423
O-Ring
45
02896-11009
O-Ring
46
20Y-62-51191
Tee
47
07002-11423
O-Ring
48
02896-11008
O-Ring
49
02896-11009
O-Ring
49
207-62-45551
Hose Assembly
50
02774-00320
Hose
51
02774-00332
Hose
52
20Y-62-22820
Band, Blue
53
20Y-62-22860
Band, Brown
53
207-62-45560
Hose Assembly
54
02762-00515
Hose, Face Seal Type
55
20Y-62-22790
Band, Red
56
198-61-14180
Clip
57
04435-51712
Clip
58
01010-81235
Bolt
59
01643-31232
Washer
60
04434-51712
Clip
61
134-03-61410
Band
62
08034-20536
Band
63
207-62-73570
Block
64
207-62-45650
Hose Assembly
65
207-62-45730
Hose Assembly
66
207-62-45510
Bracket
