LUBE МАСЛООХЛАДИТЕЛЬ

Запчасти Komatsu PC400LC-5 LUBE МАСЛООХЛАДИТЕЛЬ СИСТЕМА СМАЗКИ МАСЛ. СИСТЕМА

Схема запчастей Komatsu PC400LC-5 - LUBE МАСЛООХЛАДИТЕЛЬ СИСТЕМА СМАЗКИ МАСЛ. СИСТЕМА
25
25
17
17
25
16
18
25
24
7
14
8
7
8
22
13
23
9
10
2
21
19
3
6
12
11
15
31
4
26
5
1
32
29
20
28
30
27
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$0

1294 482 H91

HEAD, LUBE OIL FILTER

1

1294 147 H1

HEAD, LUBE OIL FILTER

2

1294 146 H1

PLUNGER, BYPASS VALVE

3

1294 151 H1

SPRING, COMPRESSION

4

1294 148 H1

RING, RETAINING

5

1294 149 H1

RING, RETAINING

6

1294 145 H1

THERMOSTAT

|$7

1246 118 H91

PLUG, THREADED

7

NSS

PLUG, THREADED

8

1246 119 H1

O-RING

|$10

1246 131 H91

PLUG, THREADED

9

NSS

PLUG, THREADED

10

1240 473 H1

O-RING

|$13

1294 484 H1

PLUG, THREADED

11

NSS

PLUG, THREADED

12

1294 110 H1

O-RING

13

1239 158 H1

PLUG, PIPE

14

1239 159 H1

PLUG, PIPE

15

1294 150 H1

PLUG, EXPANSION

16

1246 160 H1

BOLT

17

1294 141 H1

HOSE, PLAIN

18

1294 485 H1

BOLT

19

1296 282 H1

BOLT, W/WASHER

20

1296 859 H1

SEAL, RECTANGULAR RING

21

1294 140 H1

GASKET, FILTER

22

1240 555 H2

GASKET, OIL COOLER SUPPORT

23

1240 554 H1

BOLT, W/WASHER

24

1246 349 H1

COOLER, LUBRICATING OIL

25

1239 537 H1

CLAMP, HOSE

26

1240 012 H1

PIN, ROLL

27

1246 346 H1

UNION, MALE

28

1246 363 H1

ELBOW, MALE UNION

29

1296 860 H1

ADAPTER, FILTER HEAD

30

1296 861 H1

COVER, FILTER HEAD

31

1296 862 H1

SEAL, RECTANGULAR RING

32

1296 863 H1

SEAL, RECTANGULAR RING
