ТОПЛИВН. НАСОС ПЕРЕДН. COVER

Запчасти Komatsu PC400LC-5 ТОПЛИВН. НАСОС ПЕРЕДН. COVER ТОПЛИВН. СИСТЕМА

Схема запчастей Komatsu PC400LC-5 - ТОПЛИВН. НАСОС ПЕРЕДН. COVER ТОПЛИВН. СИСТЕМА
29
27
31
30
28
10
38
21
2
19
7
22
20
18
3
16
11
15
25
26
8
9
5
1
29
12
23
35
13
33
32
17
31
30
28
2
39
37
6
36
14
34
40
42
24
41
4
43
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$0

1239 601 H91

COVER, FRONT FUEL PUMP

|$1

1239 574 H91

COVER AND BUSHING

1

1239 494 H2

COVER, FUEL PUMP

2

1238 391 H1

BUSHING

3

1238 859 H1

SEAL, OIL

4

1238 865 H1

HUB, JAW COUPLING

5

1238 867 H1

KEY, SQUARE

6

1238 858 H1

GEAR, TACHOMETER DRIVE

|$8

1239 339 H91

SHAFT, TACHOMETER DRIVE

7

1238 862 H1

SHAFT, TACHOMETER DRIVE

8

1238 863 H1

BUSHING, TACHOMETER DRIVE

9

1238 864 H1

GEAR, TACHOMETER DRIVE

10

1239 025 H1

CONNECTOR, MALE

11

1239 092 H1

SPACER, SEAL

|$14

1239 575 H91

DRIVE ASSEMBLY, MAIN

12

1238 050 H1

BEARING, BALL

13

1238 857 H1

SHAFT, FUEL PUMP DRIVE

14

1238 860 H1

RING, RETAINING

15

1238 861 H1

GEAR, FUEL PUMP

16

1238 866 H1

ADAPTER, SPLINE

17

1241 525 H1

SEAL, OIL

|$21

1237 931 H91

SHAFT, IDLER GEAR

18

1238 266 H1

RING, RETAINING

19

1238 593 H1

BUSHING

20

1238 602 H1

RING, THRUST

|$25

1237 940 H91

SHAFT ASSEMBLY, GEAR

21

1238 195 H1

GEAR, IDLER

22

1238 592 H1

SHAFT

23

1238 005 H1

BOLT

24

1238 334 H1

WASHER, PLAIN

25

1238 068 H1

BOLT

26

1240 081 H1

WASHER, SEALING

|$32

1239 508 H91

WEIGHT & CARRIER ASSEMBLY, GOVERNOR

27

1238 388 H1

WEIGHT, GOVERNOR

28

1238 843 H1

SHAFT, GOVERNOR

29

1238 844 H1

PIN, GOVERNOR

30

1238 845 H1

GEAR, GOVERNOR

31

1239 125 H1

CARRIER, GOVERNOR

|$38

1239 509 H91

ASSEMBLY, LOWER WEIGHT

28

1238 843 H1

SHAFT, GOVERNOR

29

1238 844 H1

PIN, GOVERNOR

30

1238 845 H1

GEAR, GOVERNOR

31

1239 125 H1

CARRIER, GOVERNOR

32

1238 337 H1

WEIGHT, GOVERNOR

33

1238 313 H1

SHIM

34

1238 308 H1

SPRING

35

1238 312 H1

PLUNGER, GOVERNOR WEIGHT ASSIST

36

1239 369 H1

BOLT, W/WASHER

37

1238 208 H1

BOLT

38

1238 590 H1

GASKET, FUEL PUMP

39

1238 104 H1

WASHER, LOCK

40

1238 155 H1

WASHER, PLAIN

41

1239 580 H1

SCREW, ROUND HEAD CAP

42

1294 586 H1

GASKET, FUEL PUMP

43

1294 740 H1

BOLT
