AFC ASSEMBLY

Запчасти Komatsu PC400LC-5 AFC ASSEMBLY ТОПЛИВН. СИСТЕМА

Схема запчастей Komatsu PC400LC-5 - AFC ASSEMBLY ТОПЛИВН. СИСТЕМА
23
17
19
18
20
22
6
21
12
7
3
8
5
4
12
1
16
13
15
9
2
10
11
14
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$0

1296 745 H91

AFC ASSEMBLY

|$1

1296 748 H91

BARREL & PLUNGER

1

NSS

PLUNGER, AIR FUEL CONTROL

2

NSS

BARREL, AIR FUEL CONTROL

3

1239 303 H1

DIAPHRAGM

4

1296 749 H1

COVER, FUEL CONTROL

5

1239 283 H1

BOLT, FILLISTER HEAD

6

1296 750 H1

NUT, LOCK

7

1296 751 H1

PISTON, AFC

8

1296 752 H1

PISTON, AFC

9

1294 101 H1

O-RING

10

1294 108 H1

O-RING

11

1294 109 H1

O-RING

12

1296 753 H1

WASHER, PLAIN

13

1296 754 H1

SHIM, AFC

13

1239 017 H1

SHIM, AFC

13

1296 755 H1

SHIM, AFC

13

1296 756 H1

SHIM, AFC

13

1296 757 H1

SHIM, AFC

14

1239 397 H1

SPRING, COMPRESSION

15

1238 053 H1

RING, RETAINING

16

1296 758 H1

SPRING, COMPRESSION

17

1240 070 H1

BOLT, FILLISTER HEAD

18

1238 182 H1

SCREW, SOCKET SET

19

1296 759 H1

COVER, PROTECTIVE

20

1296 760 H1

RETAINER, SPRING

21

1296 761 H1

NUT, LOCK

22

1296 762 H1

SPRING, COMPRESSION

23

1239 335 H91

VALVE, CHECK
