ТОПЛИВН. НАСОС РЕГУЛЯТОР ПЕРЕДН. КРЫШКАAND КОМПОНЕНТЫ

Запчасти Komatsu PC400LC-5 ТОПЛИВН. НАСОС РЕГУЛЯТОР ПЕРЕДН. КРЫШКАAND КОМПОНЕНТЫ ТОПЛИВН. СИСТЕМА

Схема запчастей Komatsu PC400LC-5 - ТОПЛИВН. НАСОС РЕГУЛЯТОР ПЕРЕДН. КРЫШКАAND КОМПОНЕНТЫ ТОПЛИВН. СИСТЕМА
19
5
30
6
25
31
23
20
24
26
32
18
22
9
2
21
27
4
33
8
34
17
1
16
15
14
13
12
11
29
7
10
3
28
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$1

ND190800-2460

GOVERNOR, FUEL PUMP - FRONT

1

ND090810-0390

HOUSING

2

ND090878-0040

PLATE

3

ND091024-0031

SCREW, ADJUSTING

4

ND090901-0150

LEVER ASSEMBLY, TENSION

5

ND090930-0490

LEVER ASSEMBLY, CONTROL

6

ND090894-0010

E-RING

7

ND948053-0051

NUT

8

ND091046-0010

SLIDER, SUPPORT

9

ND090970-0350

SHACKLE ASSEMBLY

10

ND949130-0050

KEY, WOODRUFF

11

ND090840-0520

FLYWEIGHT ASSEMBLY

12

ND949015-0500

WASHER, (0.25 MM) - SPRING

13

ND090844-0010

NUT

14

ND090860-0200

SLEEVE SUB-ASSEMBLY

15

ND090868-0040

PLATE, THRUST

16

ND90567-30000

RING, SNAP

17

ND949013-4090

WASHER, (0.1 MM)

|$19

ND949013-4060

WASHER, (0.2 MM)

|$20

ND949013-4070

WASHER, (0.3 MM)

|$21

ND949013-4080

WASHER, (0.4 MM)

|$22

ND949013-4100

WASHER, (1.0 MM)

18

ND090992-0420

SPRING, CONTROL

19

ND090993-0280

SPRING, START

|$25

ND090910-1150

ADAPTER

20

ND090911-0010

SCREW

21

ND090919-0010

ADAPTER

22

ND090918-1950

SPRING, GOVERNOR

23

ND090894-0010

E-RING

24

ND949013-3880

WASHER, (0.10 MM)

|$31

ND949013-4040

WASHER, (0.20 MM)

|$32

ND949013-4020

WASHER, (0.25 MM)

|$33

ND949013-4030

WASHER, (0.50 MM)

|$34

ND949013-7880

WASHER, (1.00 MM)

25

ND090923-0011

NUT, LOCK

26

ND090224-0140

PLUG

27

ND949018-1550

WASHER

28

ND090119-0040

GASKET

29

ND090823-0230

GASKET

30

ND090245-0230

SCREW

31

ND090222-0120

WASHER

32

ND949047-0620

BOLT

33

ND91418-06201

BOLT

34

ND91518-06161

BOLT
