Запчасти Komatsu PC400LC-6LC FIG NO. N-A МОТОР ПОВОРОТА МОТОР / ПОВОРОТН. КРУГ И КОМПОНЕНТЫ
15
34
3
14
1
16
6
2
33
4
13
5
12
8
18
28
27
9
19
10
20
11
21
7
32
22
17
25
29
24
31
23
30
26
|$0
706-77-01180
MOTOR ASSEMBLY, SWING
1
706-77-43210
CASE, MOTOR
2
706-77-43180
BOLT
3
706-7E-11440
O-RING
4
706-77-40010
BEARING
5
706-77-43840
PLATE, VALVE
6
708-18-13230
PIN
7
706-77-43080
SHAFT, CENTER
8
706-77-43191
BLOCK,CYLINDER
9
706-77-42110
SPRING
10
706-77-42130
RING, CENTER
11
706-77-42160
PISTON SUB ASSEMBLY
12
706-77-42041
SEAT
13
706-77-42051
SPRING
14
706-77-43260
RETAINER
15
706-75-41271
SCREW
16
706-77-43860
SHAFT
17
706-77-43880
BEARING
18
706-77-42890
BEARING
|$19
706-77-05010
SPACER KIT
19
NSS
SPACER, 2.3MM
20
NSS
SPACER, 2.5MM
21
NSS
SPACER, 2.7MM
22
04064-06525
RING, SNAP
23
706-77-43060
COVER
24
07000-02125
O-RING
25
706-77-43950
SEAL, OIL
26
04071-00130
RING, SNAP
27
706-77-91540
PLATE
28
706-77-91550
DISC
29
706-77-91580
PISTON, BRAKE
30
07000-15180
O-RING
31
708-8H-15220
O-RING
32
706-75-42830
PIN, DOWEL
33
706-77-91510
SPRING
34
706-77-72510
HOUSING
