МАСЛ. УПРАВЛЯЮЩ. КЛАПАН

Запчасти Komatsu PC400LC-6LC МАСЛ. УПРАВЛЯЮЩ. КЛАПАН ДВИГАТЕЛЬ

Схема запчастей Komatsu PC400LC-6LC - МАСЛ. УПРАВЛЯЮЩ. КЛАПАН ДВИГАТЕЛЬ
17
6
7
25
2
21
30
23
31
12
19
20
24
27
26
18
24
18
5
1
34
4
16
33
8
28
15
32
3
18
29
13
11
9
24
22
16
14
10
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$0

1310 691 H91

VALVE, OIL CONTROL

1

1307 044 H91

BARREL AND PLUNGER

2

1307 050 H1

BODY, VALVE

3

1307 047 H1

COVER, OIL CONTROL VALVE

4

1307 049 H1

COVER, DIAPHRAGM

5

1307 052 H1

DISC. VALVE

6

1307 041 H1

SPRING, LEAF

7

1307 048 H1

GASKET, VALVE

8

1307 039 H1

SEAL, O-RING

9

1294 109 H1

SEAL, O-RING

10

1294 108 H1

SEAL, O-RING

11

6216-94-3940

SEAL, O-RING

12

1307 473 H1

BOLT (1/4 - 28x1 1/2 INCH)

13

1296 760 H1

RETAINER, SPRING

14

1307 300 H1

SPRING, COMPRESSION

15

1238 053 H1

RING, RETAINING

16

1296 995 H1

NUT, LOCK

17

1239 067 H1

SEAL, WIRE

18

1240 059 H1

WASHER, PLAIN

19

1307 051 H1

WASHER, PLAIN

20

1307 053 H1

BOLT

21

1307 038 H91

NUT, SEALING

22

1307 054 H1

BOLT (1/4 - 20x7/8 INCH)

23

1307 055 H1

BOLT (1/4 - 20x2 1/2 INCH)

24

1238 480 H1

WASHER, LOCK

25

1307 042 H1

NUT, CONTROL VALVE

|$26

1307 040 H91

PLUG, THREADED

26

NSS

PLUG, THREADED

27

1296 846 H1

O-RING

28

1238 159 H1

NAMEPLATE

29

1238 083 H1

SCREW

|$31

1239 661 H91

PLUG, THREADED

30

NSS

PLUG, THREADED

31

1239 669 H1

O-RING

32

1241 481 H1

ELBOW, MALE UNION

33

1296 846 H1

O-RING

34

1240 950 H1

BOLT (M8x1.25x80)

N/I

1307 303 H91

KIT, STC VALVE REPAIR
