ВОДЯНАЯ ПОМПА

Запчасти Komatsu PC400LC-6LC ВОДЯНАЯ ПОМПА ДВИГАТЕЛЬ

Схема запчастей Komatsu PC400LC-6LC - ВОДЯНАЯ ПОМПА ДВИГАТЕЛЬ
22
15
23
16
4
9
14
24
23
19
6
21
20
17
18
2
1
12
23
22
8
7
3
5
10
11
13
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$0

1295 271 H91

PUMP, WATER ASSEMBLY

1

1240 443 H2

SEAL, O-RING

2

1246 568 H1

GASKET, CONNECTION

3

1238 047 H1

BEARING, BALL

4

1294 219 H1

SEAL, O-RING

5

1246 575 H1

RING, RETAINING

6

1239 655 H2

SEAL, WATER PUMP

7

1268 144 H1

RING, RETAINING

8

1246 576 H1

SEAL, OIL

9

1246 579 H1

IMPELLER, WATER PUMP

10

1294 220 H1

SHAFT, WATER PUMP

11

1246 580 H1

GEAR, WATER PUMP

12

1294 221 H1

BODY, WATER PUMP

13

1294 222 H1

SEAL, O-RING

14

1294 005 H1

BOLT (M10x1.50x25)

15

6732-11-1910

PLUG, PIPE (1/2 NPT)

16

6742-01-1460

PLUG, PIPE (1 NPT)

17

1246 584 H1

CONNECTION, WATER TRANSFER

18

1246 160 H1

BOLT (M10x1.50x30)

19

6732-21-5160

BOLT (M8x1.25x25)

20

1307 125 H1

COVER, WATER PUMP

21

1267 723 H91

NIPPLE, COUPLING

22

1246 119 H1

SEAL, O-RING

|$23

1246 118 H91

PLUG, THREADED

23

NSS

PLUG, THREADED (9/16x18 IN)

24

1246 119 H1

O-RING
