/ / / / / / FIG. H8-A ГИДРАВЛ - ГЛАВН. КЛАПАН
Запчасти Komatsu PC400LC-6LM FIG. H8-A ГИДРАВЛ - ГЛАВН. КЛАПАН ГИДРАВЛИКА
36
17
27
19
15
28
18
24
16
12
13
33
14
10
35
34
25
31
33
26
30
29
1
32
38
37
33
39
9
11
2
23
3
8
20
1
22
21
4
5
6
7
|$0
702-21-09147
VALVE, PILOT
|$1
702-21-55100
VALVE ASSEMBLY, RELIEF
1
NSS
SLEEVE
2
NSS
COLLAR
3
NSS
FILTER
4
NSS
POPPET
5
NSS
SPRING
6
NSS
SCREW
7
NSS
NUT
8
NSS
O-RING
9
702-16-53920
O-RING
10
NSS
O-RING
11
07002-11623
O-RING
12
NSS
BLOCK
13
702-21-55310
VALVE
14
702-21-55460
SPRING
15
702-21-55420
O-RING
16
702-21-55520
O-RING
17
702-21-55440
O-RING
18
702-21-53120
FILTER
19
07000-11009
O-RING
20
702-21-55410
PLATE
21
01252-60820
BOLT
22
01643-50823
WASHER
23
702-21-55530
O-RING
24
NSS
BLOCK
25
NSS
SPOOL
26
702-21-55640
SPRING
27
702-21-55620
PLUG
28
07002-11423
O-RING
29
702-21-55710
SEAT
30
702-21-55720
SPRING
31
04260-00793
BALL
32
07000-11009
O-RING
33
NSS
PLUG
34
702-21-55670
ORIFICE
35
702-21-55470
ORIFICE
36
01252-60520
BOLT
37
702-21-55480
FRANGE
38
07000-12020
O-RING
39
01252-61025
BOLT
