/ / / / / / A-BL ТУРБОНАГНЕТАТЕЛЬ KTR9-E
Запчасти Komatsu PC400LC-8 A-BL ТУРБОНАГНЕТАТЕЛЬ KTR9-E ДВИГАТЕЛЬ
19
18
12
11
7
9
1
17
20
23
22
6
8
21
5
16
15
14
10
4
13
3
2
|$0
6506-21-5020
TURBOCHARGER ASSEMBLY
|$1
6506-21-5910
CORE ASSEMBLY
1
NSS
ROTOR, TURBINE
2
NSS
PLATE, COLLAR
3
NSS
SPACER, COLLAR
4
NSS
FLINGER
5
NSS
IMPELLER, BLOWER
6
NSS
NUT, LOCK
7
NSS
BEARING, JOURNAL
8
NSS
BEARING, THRUST
9
NSS
RING, SEAL TURBINE
10
NSS
RING, SEAL TURBINE
11
NSS
SHIELD, HEAT
12
NSS
HOUSING, CENTER
13
NSS
PIN, DOWEL
14
NSS
O-RING
15
NSS
INSERT
16
NSS
RING, SNAP
17
6506-21-4230
HOUSING, TURBINE
18
6505-11-0520
PLATE
19
01020-01016
BOLT
20
6506-21-2030
HOUSING, BLOWER
21
6501-11-1721
V-BAND
22
6505-99-9011
PLATE, NAME
23
04418-02550
SCREW
