/ / / / / / ОХЛАЖД-Е (МАСЛООХЛАДИТЕЛЬ И КОЖУХ)
Запчасти Komatsu PC400LCSE-8R ОХЛАЖД-Е (МАСЛООХЛАДИТЕЛЬ И КОЖУХ) C
24
17
23
33
25
15
16
39
21
22
6
1
5
2
6
3
20
6
4
38
14
14
7
32
40
9
31
11
19
12
18
13
10
6
14
34
14
41
30
13
29
10
8
26
37
36
28
35
27
|$1
208-03-76101
COOLER ASS'Y
|$2
208-03-76110
OIL COOLER ASS'Y
1
208-03-71860
SEAL
2
OIL COOLER
3
OIL COOLER
4
OIL COOLER
5
208-03-75670
SEAL
6
208-03-75870
SEAL
7
208-03-76120
FRAME
8
208-03-77280
SEAL
9
208-03-77320
SEAL
10
BOLT
11
01010-81020
BOLT
12
01643-31032
WASHER
13
WASHER
14
O-RING
15
01010-81225
BOLT
16
01643-31232
WASHER
17
01010-81040
BOLT
18
01643-31032
WASHER
19
124-54-26540
WASHER
20
208-03-75450
NET
21
01434-10616
BOLT, WING
22
01643-30623
WASHER
23
208-03-75440
NET
24
01434-10616
WING BOLT
25
01643-30623
WASHER
26
208-03-77390
SHROUD
27
01010-81020
BOLT
28
01643-31032
WASHER
29
01010-81030
BOLT
30
01643-31032
WASHER
31
208-03-76381
COVER
|$34
208-03-76380
COVER
32
01010-81030
BOLT
33
01643-31032
WASHER
34
208-03-77360
SEAL
35
208-03-77141
COVER
|$39
208-03-77140
COVER
36
01010-81020
BOLT
37
01643-31032
WASHER
38
208-03-77250
SEAL
39
208-03-77350
SEAL
40
208-03-75970
SEAL
41
208-03-75980
SEAL
