ТОПЛИВН. НАСОС (/)(НАСОС)(ВНУТР. ЧАСТИ)(№-UP)

Запчасти Komatsu PC400LCSE-8R ТОПЛИВН. НАСОС (/)(НАСОС)(ВНУТР. ЧАСТИ)(№-UP) A

Схема запчастей Komatsu PC400LCSE-8R - ТОПЛИВН. НАСОС (/)(НАСОС)(ВНУТР. ЧАСТИ)(№-UP) A
2
3
4
7
6
2
5
8
9
10
11
1
18
19
13
17
16
14
15
37
12
28
27
31
30
32
33
21
13
20
22
34
35
36
29
28
24
23
25
26
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$1

6251-71-1121

PUMP ASS'Y, FUEL INJECTION

|$2

ND094100-0460

BODY ASS'Y

1

ND094110-0210

HOUSING ASS'Y

2

ND094040-0370

ELEMENT ASS'Y

3

ND094086-0090

O-RING

4

ND094140-0040

VALVE ASS'Y

5

ND094086-0100

O-RING

6

ND949013-5880

WASHER

7

ND921560-8081

NUT

8

ND094162-0040

SEAT

9

ND094164-0010

SPRING

10

ND094165-0021

SEAT

11

ND094170-0100

TAPPET ASS'Y

12

ND094191-0161

CAMSHAFT

13

ND949101-0230

BEARING, ROLLER

14

ND094104-0100

COVER

15

ND949150-3030

SEAL, OIL

16

ND094086-0120

O-RING

17

ND094095-0100

SHIM, T=0.05MM

|$20

ND094095-0130

SHIM, T=0.10MM

|$21

ND094095-0140

SHIM, T=0.20MM

|$22

ND094095-0150

SHIM, T=0.30MM

|$23

ND094095-0160

SHIM, T=0.50MM

18

ND094092-0010

WASHER

19

ND949044-3320

BOLT

20

ND094086-0110

O-RING

21

ND094086-0130

O-RING

22

ND094093-0050

SHIM, T=0.40MM

|$29

ND094093-0060

SHIM, T=0.60MM

|$30

ND094093-0070

SHIM, T=0.80MM

|$31

ND094093-0080

SHIM, T=1.00MM

23

ND949979-1300

SENSOR ASS'Y

|$33

ND949140-6310

O-RING

24

ND094096-0050

SHIM, T=0.15MM

|$35

ND094096-0060

SHIM, T=0.20MM

|$36

ND094096-0070

SHIM, T=0.25MM

|$37

ND094096-0080

SHIM, T=0.40MM

25

ND902000-6081

WASHER

26

ND901070-6161

BOLT

27

ND090310-0500

VALVE ASSY

28

ND090222-0070

WASHER

29

ND949180-0310

SCREW

30

ND090222-0120

WASHER
