ОСНОВН. НАСОС (8/)

Запчасти Komatsu PC400LCSE-8R ОСНОВН. НАСОС (8/) Y

Схема запчастей Komatsu PC400LCSE-8R - ОСНОВН. НАСОС (8/) Y
15
16
21
22
20
28
18
19
17
26
23
24
25
27
7
6
5
8
9
10
29
3
2
4
11
12
1
14
13
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$1

708-2H-00450

PUMP ASS'Y

|$2

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$3

SHOWN IN FIGS.Y1600-01A0 T0 Y1600-12A0.

|$4

708-2H-01450

PUMP SUB ASS'Y

1

708-2H-34150

SLIDER

|$6

708-2H-03411

VALVE ASS'Y, PC

|$7

708-2H-03022

PISTON A.,SERVO

2

PISTON, SERVO

3

SCREW

4

708-2G-15320

SEAL

5

708-2H-15310

PLUG

6

708-2L-35760

BALL

7

708-2L-35770

PLUG

8

708-2L-35690

SEAL

9

708-2L-35170

PIN

10

708-3M-15670

SPOOL

11

708-2G-15290

RETAINER

12

708-2G-15140

SEAT

13

708-2H-15330

SPRING

14

708-2H-15320

SPRING

15

708-2G-15151

SEAT

16

708-2H-15340

SPRING

17

708-2G-14340

SCREW

18

07000-B3038

O-RING

19

708-2G-15230

RING,BACK UP

20

708-2G-15260

SEAL

21

708-2G-15240

PLUG

22

07000-B2012

O-RING

23

07000-B2050

O-RING

24

708-2G-15310

RING

25

708-2L-44161

COVER

26

01580-10806

NUT

27

708-2L-35540

NUT

28

708-2G-15330

RING,WIRE

29

01252-61645

BOLT
