Запчасти Komatsu PC400LCSE-8R ОСНОВН. КЛАПАН ( ACTUTOR) (/) Y

|$1

723-48-27504

CONTROL VALVE

|$2

723-48-27503

CONTROL VALVE

|$3

723-48-27502

CONTROL VALVE

|$4

723-48-27501

CONTROL VALVE

|$5

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$6

SHOWN IN FIGS.Y1664-01A0 TO Y1664-23A0.

1

723-40-87400

VALVE ASS'Y

|$8

723-40-87110

BODY

2

723-40-87440

SPOOL

3

723-40-87260

SPRING

4

SLEEVE

5

SEAL

6

CASE

7

723-40-87250

RETAINER

8

723-40-87170

O-RING

9

07000-13035

O-RING

10

07000-11007

O-RING

11

SCREW

12

01252-60830

BOLT

13

01252-61075

BOLT

14

07000-13038

O-RING

15

07000-11010

O-RING
