/ / / / / / K-A КАБИНА ПЕРЕДН. ОКНА АНТИВАНДАЛЬН.
Запчасти Komatsu PC450LC-8 K-A КАБИНА ПЕРЕДН. ОКНА АНТИВАНДАЛЬН. OPERATOR\XD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ
46
47
45
44
37
38
34
36
22
1
40
41
39
42
39
24
25
23
30
31
26
28
27
2
3
29
37
38
35
32
36
33
4
13
10
9
11
12
8
13
16
18
17
14
5
12
11
19
7
6
20
21
43
14
15
|$1
20Y-53-00031
WINDOW ASSEMBLY
1
20Y-53-11511
FRAME
2
20Y-53-11520
GLASS
3
20Y-54-51531
SEAL
4
20Y-53-11551
SEAL
5
22B-54-15411
LOCK ASSEMBLY
6
22B-54-15440
CASE
7
22B-54-15470
KNOB
8
22B-54-15421
LOCK ASSEMBLY
9
22B-54-15450
CASE
10
22B-54-15480
KNOB
11
01010-D0816
BOLT
12
418-54-35450
WASHER
13
20Y-54-52621
ROLLER
14
20Y-54-52681
ROLLER
15
20Y-53-12330
PIN
16
20Y-54-14590
HANDLE
17
01245-00616
SCREW, SOCKET HEAD
18
01643-70623
WASHER
19
20Y-53-12830
BRACKET
20
01245-00816
SCREW, SOCKET HEAD
21
01643-70823
WASHER
22
20Y-54-51670
STOPPER
23
20Y-54-51680
STOPPER
24
01252-80616
BOLT, SOCKET HEAD
25
01643-70623
WASHER
26
20Y-53-11561
BLOCK ASSEMBLY
27
01245-00816
SCREW, SOCKET HEAD
28
01643-70823
WASHER
29
20Y-53-11661
BRACKET
30
01245-00816
SCREW, SOCKET HEAD
31
01643-70823
WASHER
32
21J-06-12440
SWITCH
33
01583-11811
NUT
34
20Y-53-11581
BRACKET
35
20Y-53-11641
BRACKET
36
01435-00612
BOLT
37
20Y-54-11611
STOPPER
38
01580-11008
NUT
39
20Y-54-51621
STRIKER
40
01584-31008
NUT, FLANGED
41
01643-71032
WASHER
42
20Y-53-11540
SEAL
43
20Y-54-51420
SEAL
44
20Y-53-12531
COVER
45
20Y-53-12310
COLLAR
46
01245-00616
SCREW, SOCKET HEAD
47
01643-70623
WASHER
