/ / / / / / 2-Я СТРЕЛА В СБОРЕ (№K9-UP)
Запчасти Komatsu PC450LC-8K HIGH REACH DEMOLITION 2-Я СТРЕЛА В СБОРЕ (№K9-UP) TABLE OF CONTENTS PC-8 ВЫС. REACH РАЗРУШ. ЗДАНИЙ
22
21
20
19
26
25
24
23
49
46
48
50
51
53
52
47
45
44
43
42
18
27
28
29
17
16
15
14
14
12
13
1
35
34
37
36
39
38
40
41
32
33
30
31
19
20
21
22
3
11
7
6
5
2
4
9
10
8
19
20
21
22
30
31
33
32
41
40
38
39
36
37
35
34
1
208-70-KD294
NO 2 BOOM ASSY
2
KV-B240-6190
FITTING
3
206-70-71272
BUSHING
4
KV-B240-6170
PIN
5
205-70-71310
PLATE
6
01010-81240
BOLT
7
01643-31232
WASHER
8
KV-B240-6180
PLATE
9
01010-82055
BOLT
10
01643-32060
WASHER
11
206-70-55250
SPACER
12
07085-01012
HOSE
13
07085-01013
HOSE
14
07000-13032
O-RING
15
07371-31049
FLANGE
16
07372-21035
BOLT
17
01643-51032
WASHER
18
208-62-KD510
TUBE
19
207-62-KG270
CLAMP
20
205-62-54622
SEAT
21
01010-81250
BOLT
22
01643-31232
WASHER
23
07371-31049
FLANGE
24
07372-21040
BOLT
25
01643-51032
WASHER
26
207-62-KH260
COUPLER
27
02756-00540
HOSE
28
02753-00440
HOSE
29
02753-00640
HOSE
30
07094-30417
CLAMP
31
07095-00420
CUSHION
32
07094-30518
CLAMP
33
07095-00526
CUSHION
34
07094-10620
CLAMP
35
07095-00627
CUSHION
36
07094-10518
CLAMP
37
07095-00526
CUSHION
38
01011-81240
BOLT
39
01643-31232
WASHER
40
01011-81245
BOLT
41
01643-31232
WASHER
42
07378-11000
HEAD
43
07371-31049
FLANGE
44
07372-21035
BOLT
45
01643-51032
WASHER
46
21P-62-K3240
BAND (RED)
47
21P-62-K3250
BAND (YEL)
48
21P-62-K3260
BAND (BLK)
49
21P-62-K3270
BAND (WHT)
50
21P-62-K3280
BAND (BLK)
51
21P-62-K3290
BAND (GRN)
52
21P-62-K3310
BAND (BRN)
53
207-62-KH810
BAND (GREY)
