/ / / / / / 3-Я СТРЕЛА (QC+ПАЛЕЦ И ВТУЛКАS) (№K8-K8)
Запчасти Komatsu PC450LC-8K HIGH REACH DEMOLITION 3-Я СТРЕЛА (QC+ПАЛЕЦ И ВТУЛКАS) (№K8-K8) TABLE OF CONTENTS PC-8 ВЫС. REACH РАЗРУШ. ЗДАНИЙ
54
121
53
126
52
17
51
9
61
62
63
34
77
78
79
80
71
70
69
47
48
35
72
119
49
50
36
88
120
87
86
85
57
56
55
89
125
124
123
37
90
45
46
122
38
32
33
73
74
75
76
41
42
43
39
58
59
64
65
66
44
84
83
82
81
40
115
116
60
67
68
117
118
93
92
91
16
15
113
112
111
114
28
153
11
12
27
110
13
14
19
20
26
109
1
21
10
108
24
23
96
127
128
25
95
29
8
7
6
94
30
18
5
22
99
105
31
4
100
106
101
107
102
104
3
103
97
98
2
152
141
139
149
150
151
131
130
129
140
143
142
145
146
147
148
136
137
138
144
135
134
133
132
1
208-70-KD311
No. 3 BOOM ASSY
2
02753-00666
HOSE
3
208-62-KB880
TUBE
4
208-70-KC770
TUBE
5
02753-00635
HOSE
6
07085-21018
HOSE
7
07371-31049
FLANGE
8
07372-21035
BOLT
9
07000-13032
O-RING
10
02753-00419
HOSE
11
07085-21012
HOSE
12
07000-13032
O-RING
13
07371-31049
FLANGE
14
07375-21035
BOLT
15
207-62-KG220
FLANGE
16
07000-13032
O-RING
17
07371-31049
FLANGE
18
208-62-KC810
TUBE
19
02782-10315
ELBOW
20
02896-11009
O-RING
21
07002-12034
O-RING
22
208-70-KC820
TUBE
23
02781-00315
UNION
24
02896-11009
O-RING
25
07002-12034
O-RING
26
02781-00422
UNION
27
02896-11012
O RING
28
07002-12034
O-RING
29
02758-00528
HOSE
30
02753-00336
HOSE
31
08034-20536
BAND
32
20Y-62-19330
ELBOW
33
120-54-42430
SPACER
34
207-62-KG380
CLAMP
35
01010-81260
BOLT
36
01643-31232
WASHER
37
07094-10518
CLAMP
38
07095-00526
CUSHION
39
01011-81235
BOLT
40
01643-31232
WASHER
41
07094-30518
CLAMP
42
07095-00526
CUSHION
43
01011-81245
BOLT
44
01643-31232
WASHER
45
KVB-24-08080
BLOCK
46
198-33-12380
WASHER
47
KVB-24-08080
BLOCK
48
198-33-12380
WASHER
49
01011-81200
BOLT
50
01643-31232
WASHER
51
07094-10315
CLAMP
52
07095-00316
CUSHION
53
01010-81285
BOLT
54
01643-31232
WASHER
55
207-62-88910
CLAMP
56
01010-81250
BOLT
57
01643-31232
WASHER
58
207-62-88950
CLAMP
59
01010-81250
BOLT
60
01643-31232
WASHER
61
207-62-88960
CLAMP
62
01010-81250
BOLT
63
01643-31232
WASHER
64
07094-10620
CLAMP
65
07095-10627
CUSHION
66
198-33-12380
WASHER
67
01011-81210
BOLT
68
01643-31232
WASHER
69
207-62-88891
CLAMP
70
205-62-54622
SEAT
71
01010-81250
BOLT
72
01643-31232
WASHER
73
207-62-88880
CLAMP
74
01010-81250
BOLT
75
01643-31232
WASHER
76
208-62-85780
CUSHION
77
207-62-88690
CLAMP
78
01010-81250
BOLT
79
01643-31232
WASHER
80
208-62-85780
CUSHION
81
07094-10620
CLAMP
82
07095-10627
CUSHION
83
01010-81295
BOLT
84
01643-31232
WASHER
85
207-62-88981
CLAMP
86
01010-81260
BOLT
87
01643-31232
WASHER
88
207-62-88960
CLAMP
89
01010-81250
BOLT
90
01643-31232
WASHER
91
207-62-88950
CLAMP
92
01010-81250
BOLT
93
01643-31232
WASHER
94
208-70-82880
ROD
95
KV-C120-3140
PIN
96
KV-C120-3150
PIN
97
707-01-XU781
ARM CYLINDER
98
707-01-XZ981
ARM CYLINDER
99
208-70-84850
PIN
100
205-70-61560
PLATE
101
01010-82045
BOLT
102
01643-32060
WASHER
103
208-70-31310
SPACER
104
208-70-84870
BUSHING
105
KV-1B27-1160
HOLDER
106
01010-82055
BOLT
107
01643-32060
WASHER
108
07020-00675
FITTING
109
207-70-11360
SPACER
110
208-70-31190
PIN
111
205-70-66580
PLATE
112
01010-81235
BOLT
113
01643-31232
WASHER
114
07020-00675
FITTING
115
01010-81295
BOLT
116
01643-31232
WASHER
117
07095-00627
CUSHION
118
07094-10620
CLAMP
119
07094-10417
CLAMP
120
07095-00420
CUSHION
121
01011-81205
BOLT
122
01643-31232
WASHER
123
07094-10417
CLAMP
124
07095-00420
CUSHION
125
01011-81205
BOLT
126
01643-31232
WASHER
127
207-62-KF350
NIPPLE
128
02896-61018
O-RING
129
207-62-KF350
NIPPLE
130
07002-12034
O-RING
131
02896-61018
O-RING
132
KV-B24-8080
BLOCK
133
198-33-12380
SPACER
134
01010-81290
BOLT
135
01643-31232
WASHER
136
207-62-KF350
NIPPLE
137
07002-12034
O-RING
138
02896-61018
O-RING
139
08034-20536
BAND
140
02753-00624
HOSE
141
02753-00323
HOSE
142
02781-00315
UNION
143
07002-12034
O-RING
144
02896-11009
O-RING
145
KV-B24-8080
BLOCK
146
198-33-12380
SPACER
147
01010-81290
BOLT
148
01643-31232
WASHER
149
02781-00422
UNION
150
07002-12034
O-RING
151
02896-11012
O-RING
152
02753-00466
HOSE
153
02753-00419
HOSE
