/ / / / / / 3-Я СТРЕЛА (QC+ПАЛЕЦ И ВТУЛКАS) (№K9-UP)
Запчасти Komatsu PC450LC-8K HIGH REACH DEMOLITION 3-Я СТРЕЛА (QC+ПАЛЕЦ И ВТУЛКАS) (№K9-UP) TABLE OF CONTENTS PC-8 ВЫС. REACH РАЗРУШ. ЗДАНИЙ
31
32
33
34
35
36
37
29
30
38
39
40
41
42
43
54
53
52
44
45
46
47
51
50
49
48
58
59
60
69
68
67
66
55
56
57
25
24
23
16
17
18
61
62
63
64
65
81
80
79
78
90
89
11
12
13
14
1
74
75
76
77
84
83
116
117
118
119
70
71
72
73
112
113
114
115
150
110
109
108
107
123
122
121
120
10
106
111
88
82
85
86
87
105
93
92
91
96
97
98
102
103
104
4
15
9
8
7
6
5
21
20
22
26
27
19
28
124
125
3
2
94
101
149
138
139
140
141
142
143
144
145
146
147
148
128
127
126
136
133
134
135
132
131
130
129
137
95
99
100
1
208-70-KD311
No. 3 BOOM ASSY
2
02753-00666
HOSE
3
208-62-KB880
TUBE
4
208-70-KC770
TUBE
5
02753-00635
HOSE
6
07085-21018
HOSE
7
07371-31049
FLANGE
8
07372-21035
BOLT
9
07000-13032
O-RING
10
02753-00419
HOSE
11
07085-01013
HOSE
12
07000-13032
O-RING
13
07371-31049
FLANGE
14
07375-21035
BOLT
15
208-62-KC810
TUBE
16
02782-10315
ELBOW
17
02896-11009
O-RING
18
07002-12034
O-RING
19
208-70-KC820
TUBE
20
02781-00315
UNION
21
02896-11009
O-RING
22
07002-12034
O-RING
23
02781-00422
UNION
24
02896-11012
O RING
25
07002-12034
O-RING
26
02758-00529
HOSE
27
02753-00336
HOSE
28
08034-20536
BAND
29
20Y-62-19330
ELBOW
30
120-54-42430
SPACER
31
207-62-KG380
CLAMP
32
01010-81260
BOLT
33
01643-31232
WASHER
34
07094-10518
CLAMP
35
07095-00526
CUSHION
36
01011-81235
BOLT
37
01643-31232
WASHER
38
07094-30518
CLAMP
39
07095-00526
CUSHION
40
01011-81245
BOLT
41
01643-31232
WASHER
42
KVB-24-08080
BLOCK
43
198-33-12380
WASHER
44
KVB-24-08080
BLOCK
45
198-33-12380
WASHER
46
01011-81200
BOLT
47
01643-31232
WASHER
48
07094-10315
CLAMP
49
07095-00316
CUSHION
50
01010-81285
BOLT
51
01643-31232
WASHER
52
207-62-88910
CLAMP
53
01010-81250
BOLT
54
01643-31232
WASHER
55
207-62-88950
CLAMP
56
01010-81250
BOLT
57
01643-31232
WASHER
58
207-62-88960
CLAMP
59
01010-81250
BOLT
60
01643-31232
WASHER
61
07094-10620
CLAMP
62
07095-10627
CUSHION
63
198-33-12380
WASHER
64
01011-81210
BOLT
65
01643-31232
WASHER
66
207-62-88891
CLAMP
67
205-62-54622
SEAT
68
01010-81250
BOLT
69
01643-31232
WASHER
70
207-62-88880
CLAMP
71
01010-81250
BOLT
72
01643-31232
WASHER
73
208-62-85780
CUSHION
74
207-62-88690
CLAMP
75
01010-81250
BOLT
76
01643-31232
WASHER
77
208-62-85780
CUSHION
78
07094-10620
CLAMP
79
07095-10627
CUSHION
80
01010-81295
BOLT
81
01643-31232
WASHER
82
207-62-88981
CLAMP
83
01010-81260
BOLT
84
01643-31232
WASHER
85
207-62-88960
CLAMP
86
01010-81250
BOLT
87
01643-31232
WASHER
88
207-62-88950
CLAMP
89
01010-81250
BOLT
90
01643-31232
WASHER
91
208-70-82880
ROD
92
KV-C120-3140
PIN
93
KV-C120-3150
PIN
94
707-01-XU781
ARM CYLINDER
95
707-01-XZ981
ARM CYLINDER
96
208-70-84850
PIN
97
205-70-61560
PLATE
98
01010-82045
BOLT
99
01643-32060
WASHER
100
208-70-31310
SPACER
101
208-70-84870
BUSHING
102
KV-1B27-1160
HOLDER
103
01010-82055
BOLT
104
01643-32060
WASHER
105
07020-00675
FITTING
106
207-70-11360
SPACER
107
208-70-31190
PIN
108
205-70-66580
PLATE
109
01010-81235
BOLT
110
01643-31232
WASHER
111
07020-00675
FITTING
112
01010-84295
BOLT
113
01643-31232
WASHER
114
07095-00627
CUSHION
115
07094-10620
CLAMP
116
07094-10417
CLAMP
117
07095-00420
CUSHION
118
01011-81205
BOLT
119
01643-31232
WASHER
120
07094-10417
CLAMP
121
07095-00420
CUSHION
122
01011-81205
BOLT
123
01643-31232
WASHER
124
207-62-KF350
NIPPLE
125
02896-61018
O-RING
126
207-62-KF350
NIPPLE
127
07002-12034
O-RING
128
02896-61018
O-RING
129
KV-B24-8080
BLOCK
130
198-33-12380
SPACER
131
01010-81290
BOLT
132
01643-31232
WASHER
133
207-62-KF350
NIPPLE
134
07002-12034
O-RING
135
02896-61018
O-RING
136
08034-20536
BAND
137
02753-00624
HOSE
138
02753-00323
HOSE
139
02781-00315
UNION
140
07002-12034
O-RING
141
02896-11009
O-RING
142
KV-B24-8080
BLOCK
143
198-33-12380
SPACER
144
01010-81290
BOLT
145
01643-31232
WASHER
146
02781-00422
UNION
147
07002-12034
O-RING
148
02896-11012
O-RING
149
02753-00466
HOSE
150
02753-00419
HOSE
