Запчасти Komatsu PC490-10 МЕХАНИЗМ ПОВОРОТА МЕХАНИЗМ ПОВОРОТА
1
2
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
40
41
42
43
32
30
3
47
44
46
45
49
48
17
52
51
50
39
38
37
21
20
19
18
17
16
15
14
13
10
8
7
6
4
5
9
12
11
1
207-26-71240
Ring
2
07040-11209
Plug
3
07002-11223
O-Ring
4
208-26-71190
Case
5
07049-02430
Plug
6
06000-23124
Bearing
7
06000-22326
Bearing
8
208-26-52242
Shaft
9
208-26-61290
Seal, Oil
10
208-26-71360
Cover
11
01010-81030
Bolt
12
01643-31032
Washer
13
07000-15390
O-Ring
14
208-26-71181
Carrier
15
208-26-71140
Gear
16
207-27-61230
Bearing
17
20Y-27-21250
Washer, Thrust
18
207-27-61250
Pin
19
20Y-27-21290
Pin
20
208-26-71230
Plate
21
205-32-51211
Bolt
22
208-26-71150
Gear
23
01010-81645
Bolt
24
01643-31645
Washer
25
208-26-71130
Gear
26
208-26-71241
Plate
27
208-26-71170
Carrier
28
207-26-71520
Gear
29
22U-26-21320
Bearing
30
22U-26-21240
Washer
31
207-26-71210
Pin
32
04064-04018
Ring, Snap
33
208-26-71210
Holder
34
04260-01270
Ball
35
207-26-71510
Gear
36
207-26-71261
Plate
37
144-60-11151
Valve
38
07270-21590
Tube
39
07281-00197
Clamp
40
01010-81240
Bolt
41
01643-31232
Washer
42
208-26-71510
Gauge
43
208-26-71520
Filler
44
208-871-5162
Bracket
45
01597-01009
Nut
46
01643-31032
Washer
47
07283-32738
Clip, Pipe
48
01010-81030
Bolt
49
01643-31032
Washer
50
07000-15335
O-Ring
51
01010-82480
Bolt
52
01643-32460
Washer
