ПОРШЕНЬ НАСОС, ВНУТР. ЧАСТИ (/7) (№8-8)

Запчасти Komatsu PC490LC-10 ПОРШЕНЬ НАСОС, ВНУТР. ЧАСТИ (/7) (№8-8) ПОРШЕНЬ НАСОС

Схема запчастей Komatsu PC490LC-10 - ПОРШЕНЬ НАСОС, ВНУТР. ЧАСТИ (/7) (№8-8) ПОРШЕНЬ НАСОС
31
2
1
2
5
6
7
8
9
10
12
13
14
15
16
17
18
19
21
25
26
30
30
31
11
2
20
22
23
24
3
4
28
29
27
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$0

708-2J-00010

Pump Assembly, Piston

|$1

708-1T-00580

Pump Assembly, Piston

|$2

708-1T-01580

Pump Subassembly

|$3

708-1T-04630

Case Assembly

1

Case, Pump

2

Plug

3

Sleeve

4

Ring

5

708-1T-13430

Cam, Rocker

6

04260-01270

Ball

7

708-3S-14141

Spacer

8

708-1S-13420

Pin

9

01252-60616

Bolt, Hexagon Socket Head

10

708-1T-33432

Ball, Retainer

11

708-1T-33470

Ball, Retainer

12

01252-61235

Bolt, Hexagon Socket Head

13

04020-01024

Pin, Dowel

14

708-1S-19950

Plate

15

07000-B2065

O-ring

16

01010-61025

Bolt

17

01643-31032

Washer

|$21

708-1T-04641

Cap Subassembly

|$22

708-1T-04640

Cap Subassembly

18

Cap, End

18

Cap, End

19

Plug

20

708-1S-12260

Bearing

21

720-68-19610

Pin

22

708-7T-05020

Spacer Kit

22

Spacer, T=1.6mm

22

Spacer, T=1.7mm

22

Spacer, T=1.8mm

22

Spacer, T=1.9mm

22

Spacer, T=2.0mm

22

Spacer, T=2.1mm

22

Spacer, T=2.2mm

23

708-1S-12280

Ring, Wear

24

708-1S-12330

Retainer

25

07000-B1006

O-ring

26

07000-B2130

O-ring

27

708-3T-11310

Orifice

28

708-2L-25480

Filter

29

708-2L-25490

O-ring

30

708-1L-25210

Plug

31

07002-61423

O-ring
