/ / / / / / A- PОБОД КОЛЕСАING НАСОС ТРУБЫ
Запчасти Komatsu PC490LC-10 A- PОБОД КОЛЕСАING НАСОС ТРУБЫ ДВИГАТЕЛЬ
30
31
32
32
29
32
32
42
41
43
34
20
33
20
35
19
37
18
36
27
22
23
40
39
38
25
21
38
25
28
16
10
27
24
16
26
17
15
13
11
14
1
13
2
7
12
6
44
9
8
46
45
5
4
19
3
1
6252-71-5320
TUBE
2
02896-11012
O-RING
3
6252-71-5340
HOSE
4
6252-71-5330
HOSE
5
07005-01412
SEAL, WASHER
6
6251-71-5740
BLOCK
7
04020-00616
PIN, DOWEL
8
01010-81035
BOLT
9
01643-31032
WASHER
10
6252-71-5310
HOSE
11
02896-11012
O-RING
12
07206-30812
BOLT, JOINT
13
07005-01212
SEAL, WASHER
14
6252-71-5790
HOSE
15
07206-30812
BOLT, JOINT
16
07005-01212
SEAL, WASHER
17
02896-11009
O-RING
18
6252-71-5760
TUBE
19
07005-01412
SEAL, WASHER
20
600-052-3080
CLIP
21
600-052-3100
CLIP
22
01010-81025
BOLT
23
01643-31032
WASHER
24
6252-71-5850
TUBE
25
07005-01412
SEAL, WASHER
26
6262-71-7290
BOLT
27
07005-01412
SEAL, WASHER
28
7700-45-1710
BOLT, JOINT
29
6252-71-5450
TUBE
30
6245-71-5960
BOLT
31
07206-30508
BOLT, JOINT
32
07005-00812
GASKET
33
6252-71-5750
TUBE
34
07005-01012
SEAL, WASHER
35
6252-71-5820
BRACKET
36
01010-81080
BOLT
37
01643-31032
WASHER
38
600-052-3080
CLIP
39
01010-81025
BOLT
40
01643-31032
WASHER
41
6252-71-5720
COVER
42
01011-81010
BOLT
43
01643-31032
WASHER
44
6252-71-5710
COVER
45
01010-81025
BOLT
46
01643-31032
WASHER
