/ / / / / / ЛЕВ. СЕРВОУПРАВЛ. (КАБИНА)
Запчасти Komatsu PC50MR-2 ЛЕВ. СЕРВОУПРАВЛ. (КАБИНА) СИСТЕМА УПРАВЛЕНИЯ И ОСНОВНАЯ РАМА
28
43
22
27
11
25
24
12
26
12
13
13
29
19
20
18
23
30
10
31
21
32
41
42
21
40
14
17
4
16
36
38
39
37
33
34
8
35
7
7
9
6
34
16
6
5
2
15
3
1
a
a
b
b
1
22M-43-21291
STOPPER
2
01010-D0820
BOLT
3
01643-10823
WASHER
4
22M-43-R1551
GUIDE
5
04205-10830
PIN
6
04050-12015
PIN, COTTER
7
21U-43-32430
BUSHING
8
22B-54-15560
STOPPER
9
01580-11008
NUT
10
22M-43-21111
HOUSING
11
22M-54-22140
COVER
12
01252-70616
BOLT
13
01643-10623
WASHER
14
22M-43-21660
GAS SPRING
15
04205-30822
PIN
16
37A-09-4Z028
PIN, COTTER
17
01643-10823
WASHER
18
22M-43-21151
PIN
19
01010-D0612
BOLT
20
01643-10623
WASHER
21
06124-01616
BEARING, NEEDLE
22
22M-54-R2131
COVER
23
22M-43-21640
LEVER
\23
20Y-43-22620
KNOB
24
01370-10308
SCREW
25
20Y-43-22630
KNOB, L.H.
26
20Y-43-22421
INSERT
27
20Y-43-22250
COLLAR
28
20Y-43-22261
BOOT
29
20Y-43-22370
BOOT
30
600-411-1280
NUT
31
01252-71025
BOLT
32
01643-11032
WASHER
33
22M-43-R1680
LEVER, L.H.
34
06124-01616
BEARING, NEEDLE
35
22L-09-R3770
KNOB
36
37A-09-4P119
PIN, SPRING
37
22M-43-21560
SPRING
38
37A-09-4Z028
PIN, COTTER
39
01643-10823
WASHER
40
22M-43-21170
SWITCH, ASSY.
41
37A-09-1W059
SCREW
42
01640-20610
WASHER
43
21D-06-12880
PLUG
