Запчасти Komatsu PC600-7-M1 ОСНОВНАЯ РАМА ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ
1
2
3
4
5
6
7
8
9
10
11
11
12
12
13
13
14
14
15
15
16
17
18
19
20
21
21
22
23
24
25
26
27
28
29
30
31
32
33
1
21M-46-15512
FRAME
|1
21M-46-15511
FRAME
|1
21M-46-15510
FRAME
2
205-30-71181
COVER
3
205-30-71191
GASKET
4
01010-81230
BOLT
5
01643-31232
WASHER
6
21M-54-16931
COVER
|6
21M-54-16930
COVER
7
21M-54-16910
SHEET
8
21M-54-16920
SHEET
9
01010-81225
BOLT
10
01643-31232
WASHER
11
21M-54-16962
COVER
|11
21M-54-16961
COVER
12
21M-54-16941
SHEET
|12
21M-54-16940
SHEET
13
21M-54-16950
SHEET
14
01010-81225
BOLT
15
01643-31232
WASHER
16
21M-46-15610
SHEET
17
21M-46-15620
SHEET
18
21M-46-15640
SHEET
19
21M-46-15650
SHEET
|20
207-46-71530
COVER
20
COVER
21
20Y-46-42460
SHEET
22
01010-81020
BOLT
23
01643-31032
WASHER
|24
207-46-71540
COVER
24
COVER
25
20Y-46-42460
SHEET
26
01010-81035
BOLT
27
01643-31032
WASHER
28
21M-46-15631
COVER
29
20Y-46-42460
SHEET
30
01010-81035
BOLT
31
01643-31032
WASHER
32
07049-01215
PLUG
33
07049-01620
PLUG
