Запчасти Komatsu PC650-1 ПОВОРОТН. ТОРМОЗНАЯ ГИДРОЛИНИЯ(№9-) ОПЦИОННЫЕ КОМПОНЕНТЫ

1

209-06-14150

PLATE

2

209-06-11420

SWITCH ASS'Y

3

01573-22309

SEAT,(WELDED TO REVOLVING FRAME)

4

01572-21219

SEAT,(WELDED TO REVOLVING FRAME)

5

209-06-21240

WIRING HARNESS

6

21T-06-12530

CONNECTOR

7

21T-60-12320

VALVE

8

01220-40530

SCREW

9

01601-20513

WASHER,SPRING

10

21T-60-12380

VALVE

11

01010-50845

BOLT

12

01602-20825

WASHER,SPRING

13

209-62-37560

BRACKET

14

01010-51230

BOLT

15

01643-31232

WASHER

16

07043-00312

PLUG

17

21T-62-15250

NIPPLE

18

209-62-15720

NIPPLE

19

176-62-15490

NIPPLE

20

21T-06-16450

SWITCH

21

07235-10210

ELBOW

22

07002-01423

O-RING

23

07103-20205

HOSE

24

07230-10315

UNION

25

07002-02034

O-RING

26

07102-20305

HOSE

26

07103-20305

HOSE

27

07103-20204

HOSE

28

07103-20205

HOSE

29

209-62-37540

TUBE

30

07103-20208

HOSE

31

07103-20204

HOSE

32

205-62-67420

TEE

33

01010-51040

BOLT

34

01643-31032

WASHER

35

209-62-37570

BRACKET

36

01010-51225

BOLT

37

01643-31232

WASHER

38

07103-20211

HOSE

39

07235-10210

ELBOW

40

07002-01423

O-RING

41

20D-62-12180

ELBOW

42

07002-01423

O-RING

43

07103-20315

HOSE

44

07103-20312

HOSE

45

07230-10315

UNION

46

07002-02034

O-RING

47

209-62-37511

TUBE

47

209-62-37510

TUBE

48

209-62-37521

TUBE

48

209-62-37520

TUBE
