Запчасти Komatsu PC650-3 & PC650LC-3 МОТОР ДРЕНАЖН. ТРУБЫ УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ
40
41
10
39
35
9
38
36
37
12
8
11
11
12
35
9
18
28
28
10
19
27
13
14
34
27
17
16
20
26
6
25
7
14
4
5
13
21
3
22
33
24
15
23
31
1
30
2
32
20
29
1
07236-10628
ELBOW
2
07002-02434
O-RING
3
07102-20612
HOSE
4
07235-10628
ELBOW
5
07002-02434
O-RING
6
209-62-57221
ELBOW
7
07002-02434
O-RING
8
07297-01013
HOSE
9
07371-31049
FLANGE, SPLIT
10
07000-03032
O-RING
11
07372-21035
BOLT
12
01643-51032
WASHER
13
20D-62-11660
NIPPLE
14
07002-03334
O-RING
15
113-60-23160
FILTER
16
113-60-23151
BASE
17
21T-62-22270
VALVE ASSEMBLY, CHECK
18
01010-51025
BOLT
19
01643-31032
WASHER
20
07298-01011
HOSE
21
07000-03032
O-RING
22
07371-31049
FLANGE, SPLIT
23
07372-21035
BOLT
24
01643-51032
WASHER
25
205-62-72140
COVER
26
08034-00414
BAND
27
205-62-72240
COVER
28
08034-00536
BAND
29
07040-12414
PLUG
30
07002-02434
O-RING
35
07000-03032
O-RING
37
07000-03035
O-RING
38
209-62-31280
FLANGE
39
07371-31049
FLANGE, SPLIT
40
205-62-51310
BOLT
41
01643-51032
WASHER
