Запчасти Komatsu PC650-5 & PC650LC-5 ПЕРЕДН. ПРИВОД COVER/КОЖУХ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC650-5 & PC650LC-5 - ПЕРЕДН. ПРИВОД COVER/КОЖУХ ДВИГАТЕЛЬ
28
24
33
3
2
1
8
6
29
31
30
32
26
27
9
22
12
21
13
23
21
14
20
25
10
9
11
6
19
7
17
18
16
15
4
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

1238 062 H1

BOLT - 5/8-11 X 2 1/4

2

1238 100 H1

WASHER, LOCK

3

1238 761 H1

SUPPORT, FRONT ENGINE

4

1237 992 H1

ELBOW, MALE ADAPTER

6

1239 515 H1

PLUG, PIPE

7

1239 184 H1

SPRING, ENGINE BARRING

|$6

1241 331 H91

COVER ASSY, GEAR

8

NSS

COVER, GEAR

9

118 406

BUSHING

10

1238 671 H1

BUSHING

11

1239 360 H1

SEAL, OIL

12

1239 362 H1

SEAL, OIL

13

1239 361 H1

SEAL, OIL

14

1239 336 H1

RING, RETAINING

|$14

1239 413 H91

GUIDE ASSEMBLY, BARRING SHAFT

15

NSS

BUSHING

16

NSS

BEARING, THRUST

17

NSS

PIN, ROLL

18

NSS

GUIDE, BARRING SHAFT

19

1239 415 H1

GEAR, ENGINE BARRING

20

1239 416 H1

SHAFT, BARRING

21

1246 131 H91

PLUG, THREADED

22

1241 358 H1

PLUG, DRIVE

23

1239 901 H1

O-RING

24

1239 882 H1

PLATE, CLAMPING

25

1240 053 H1

DOWEL, PIN

26

1238 152 H1

DOWEL, DIAMOND

27

1239 321 H1

BOLT, W/WASHER - 3/8-16 X 1

28

1239 722 H1

GASKET, COVER PLATE

29

1238 132 H1

PLUG, PIPE

30

1238 753 H1

STUD

31

1238 754 H1

STUD

32

1239 440 H1

NUT, PLUG - 3/8-16

33

1241 343 H91

PLATE, GEAR COVER
