/ / / / / / НИЖН. ГИДРОЦИЛИНДР КОВША ПРЯМАЯ ЛОПАТА
Запчасти Komatsu PC650-5 & PC650LC-5 НИЖН. ГИДРОЦИЛИНДР КОВША ПРЯМАЯ ЛОПАТА РАБОЧЕЕ ОБОРУДОВАНИЕ
11
14
12
8
27
5
27
26
13
7
6
9
10
15
18
41
50
42
49
40
36
39
51
41
37
38
42
40
50
35
17
39
51
38
34
47
33
36
48
16
17
37
3
4
35
47
44
48
43
25
2
3
24
1
20
46
21
22
45
23
32
31
20
28
30
29
19
28
|$0
209-63-03061
CYLINDER ASSEMBLY
1
209-63-96540
CYLINDER
2
207-63-76170
BUSHING
3
07145-00090
SEAL, DUST (KIT)
4
07043-00108
PLUG
5
707-27-14510
HEAD, CYLINDER
6
707-51-90130
ROD, PACKING (KIT)
7
707-51-90630
RING, BUFFER (KIT)
8
707-52-90650
BUSHING
9
195-63-94170
SEAL, DUST (KIT)
10
07179-13104
RING, SNAP
11
07000-15135
O-RING (KIT)
12
07001-05135
RING, BACK-UP (KIT)
13
707-40-14910
RETAINER
14
01010-51860
BOLT
15
209-63-96520
ROD
16
707-76-90040
BUSHING
17
07145-00090
SEAL, DUST (KIT)
18
07043-00108
PLUG
|$19
707-91-01430
PISTON SUB-ASSEMBLY
19
707-37-14011
PISTON
20
130-63-12464
SEAT, VALVE
21
707-83-11100
VALVE, PISTON
22
707-80-11210
SPRING
23
707-83-11060
VALVE, PISTON
24
707-83-11070
COLLAR
25
707-83-11090
ROD
26
07000-12070
O-RING (KIT)
27
707-35-52910
RING, BACK-UP (KIT)
28
707-39-14820
RING, WEAR (KIT)
29
707-44-14180
RING, PISTON (KIT)
30
707-40-14970
SPACER
31
707-37-14020
PISTON
32
01252-31070
BOLT
33
209-62-53640
TUBE, L.H
|$35
209-62-53650
TUBE, R.H
34
209-62-53620
TUBE, L.H
|$37
209-62-53630
TUBE, R.H
35
07000-13035
O-RING (KIT)
36
01010-51060
BOLT
37
01643-31032
WASHER
38
07000-13032
O-RING
39
07378-11000
HEAD, SLEEVE
40
07371-31049
FLANGE, SPLIT
41
07372-21035
BOLT
42
01643-51032
WASHER
43
209-62-53690
BRACKET
44
209-62-53670
BRACKET
45
209-62-53680
BAND
46
209-62-53660
BAND
47
01010-51035
BOLT
48
01643-31032
WASHER
49
07282-03411
CLAMP
50
01010-51020
BOLT
51
01643-31032
WASHER
