Запчасти Komatsu PC650LC-7-M1 КЛАПАН PPC(ДЛЯ ХОДА) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
9
10
11
12
12
13
13
14
15
16
17
18
19
19
20
20
20
21
21
22
23
24
24
25
25
26
26
27
27
28
29
30
30
31
31
32
32
33
33
34
34
35
36
|1
702-16-01542
PILOT VALVE
1
BODY,VALVE
2
VALVE
3
702-16-51140
SHIM¤ 0.30MM
4
702-16-53420
SPRING
5
702-16-53140
RETAINER
6
702-16-54420
SPRING
7
702-16-53170
PISTON
8
702-16-51270
SEAL
9
07000-12020
O-RING
10
702-16-54170
COLLAR
11
702-16-54311
CASE
12
LEVER
13
SHAFT
14
PLATE
15
01010-80855
BOLT
16
01643-30823
WASHER
17
01010-80816
BOLT
18
702-16-54331
WASHER¤ 1.60MM
|18
702-16-54341
WASHER¤ 1.30MM
|18
702-16-54351
WASHER¤ 1.00MM
19
04025-00432
PIN,SPRING
20
702-16-54430
BUSHING
21
702-16-54280
SEAL,DUST
22
702-16-54506
DAMPER ASS'Y
23
01252-60525
BOLT
24
702-16-54511
PLATE
25
04025-00420
PIN,SPRING
26
LEVER
27
01224-40612
SCREW
28
PLUG
29
PLUG
30
07040-11209
PLUG
31
07002-11223
O-RING
32
BALL
33
702-16-55940
PLUG
34
702-16-55950
SEAT
35
04022-04016
PIN,DOWEL
36
04022-04010
PIN,DOWEL
