Запчасти Komatsu PC75R-2 КЛАПАН PPC(ДЛЯ ХОДА) (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ
27
A
A
c
c
b
b
a
a
1
28
2
3
4
6
29
5
22
7
10
9
11
8
35
25
26
23
36
12
21
14
12
15
16
20
19
24
15
13
14
23
25
14
33
18
32
13
31
17
21
26
34
30
29
24
30
34
31
32
33
\0
702-16-01831
PPC VALVE
1
BODY VALVE
2
VALVE
3
702-16-51140
SHIM, 0.300 mm
4
702-16-53420
SPRING
5
702-16-53140
STOPPER
6
702-16-54420
SPRING
7
702-16-53170
PISTON
8
702-16-51270
GASKET
9
702-16-54170
COLLAR
10
07000-12020
O-RING
11
702-16-57420
PLATE
12
LINK
13
702-16-54280
SEAL DUST
14
702-16-54430
BUSHING
15
04025-00432
PEG
16
702-16-57321
COVER
17
01010-80855
BOLT
18
01643-30823
WASHER
19
01010-80816
BOLT
20
702-16-54351
WASHER (1.0 mm)
20
702-16-54341
WASHER (1.3 mm)
20
702-16-54331
WASHER (1.6 mm)
21
LINK
22
01252-60525
BOLT
23
702-16-54511
SLIDER
24
04025-00420
PEG
25
LINK
26
01224-40612
SCREW
27
PLUG
28
PLUG
\28
702-16-54505
DAMPER, ASSY.
29
BODY
30
PISTON
31
O-RING
32
WASHER
33
RING, SNAP
34
PLUG
35
04022-04016
PIN
36
04022-04010
PIN
