/ / / / / / РУКОЯТЬ (ПОДУШКА) (ДЛЯ SLIDE РУКОЯТЬ) (BLUE)(№-)
Запчасти Komatsu PC78US-6 РУКОЯТЬ (ПОДУШКА) (ДЛЯ SLIDE РУКОЯТЬ) (BLUE)(№-) РАБОЧЕЕ ОБОРУДОВАНИЕ
1
2
3
3
4
4
5
5
5
6
6
6
7
8
8
9
10
11
12
13
14
14
15
15
16
16
17
17
18
18
19
20
20
21
22
23
24
25
25
1
21W-957-2290
PLATE
2
21W-957-2310
PAD
3
21W-957-2440
PLATE
4
21W-957-2320
PAD
5
01010-80816
BOLT
6
01640-20816
WASHER
7
21W-957-2360
SHIM¤ 0.5MM
|7
21W-957-2380
SHIM¤ 0.5MM
|7
21W-957-2390
SHIM¤ 1.0MM
8
21W-957-2370
SHIM¤ 0.5MM
|8
21W-957-2410
SHIM¤ 0.5MM
|8
21W-957-2420
SHIM¤ 0.5MM
9
21W-957-2330
PAD
10
01010-81040
BOLT
11
01643-31032
WASHER
12
21W-957-2350
COLLAR
13
21W-957-2160
SHIM¤ 0.5MM
|13
21W-957-2170
SHIM¤ 0.5MM
14
21W-957-2340
PAD
15
01010-80830
BOLT
16
01643-30823
WASHER
17
01580-10806
NUT
18
21W-957-2180
SHIM¤ 0.5MM
|18
21W-957-2190
SHIM¤ 1.0MM
19
21W-957-2570
ELBOW
20
21W-957-2580
NIPPLE
21
21W-957-2610
HOSE
22
21W-957-2620
HOSE
23
07020-00000
FITTING
24
21W-957-2550
PAD
25
21W-957-2560
PAD
