/ / / / / / / РУКОЯТЬ И КОВШ ТРУБЫ (№-)
Запчасти Komatsu PC78UU-8 РУКОЯТЬ И КОВШ ТРУБЫ (№-) РУКОЯТЬ И КОВШ ТРУБЫ, БЕЗ -ДОПОЛН. АКТУАТОР ТРУБЫ
19
23
19
21
3
1
2
5
4
6
35
35
20
18
16
16
18
24
17
36
34
33
32
31
15
13
14
11
10
12
9
7
8
37
30
3
6
9
15
12
17
35
38
38
39
27
27
24
20
22
22
23
21
28
29
29
28
25
26
25
26
1
21W-62-42411
Nipple
2
07002-11823
O-ring
3
02896-11009
O-ring
4
21W-62-42420
Nipple
5
07002-11823
O-ring
6
02896-11009
O-ring
7
02781-00425
Union
8
07002-12434
O-ring
9
02896-11012
O-ring
10
21W-62-42481
Nipple
11
07002-12434
O-ring
12
02896-11015
O-ring
13
02781-00422
Union
14
07002-12034
O-ring
15
02896-11012
O-ring
16
21W-62-43691
Hose, Green
17
21W-62-43711
Hose, Orange
18
21W-62-43721
Hose, Red
19
21W-62-55151
Hose, Black-White
20
21W-62-43740
Hose, Blue
21
21W-62-55141
Hose, Red-White
22
21U-62-34730
Band, Green
23
21U-62-34740
Band, Orange
24
21U-62-34760
Band, Red
25
21U-62-34770
Band, White
26
21U-62-34720
Band, Black
27
21U-62-34750
Band, Blue
28
21U-62-34770
Band, White
29
21U-62-34760
Band, Red
30
21W-62-55211
Clamp
31
21W-62-55260
Rubber
32
21W-62-55270
Rubber
33
01010-81235
Bolt
34
01643-31232
Washer
35
08034-20519
Band
36
21W-62-55280
Plug
37
21W-62-55290
Plug
38
21W-62-55240
Plug
39
21W-62-41921
Hose
|$39
21W-62-41921
Hose
