/ / / / / / / СОЕДИНЕНИЕ, СМАЗЫВАЮЩ. ЛИНИЯ
Запчасти Komatsu PC800-8E0 СОЕДИНЕНИЕ, СМАЗЫВАЮЩ. ЛИНИЯ СОЕДИНЕНИЕ
22
21
20
19
50
51
49
36
47
48
46
17
15
18
16
31
30
34
45
44
33
32
33
40
35
43
14
12
13
11
9
10
4
8
7
5
6
4
9
11
10
3
2
1
28
29
27
23
26
25
24
42
41
37
38
39
1
209-01-42232
Bracket
2
01010-81230
Bolt
3
01643-31232
Washer
4
209-01-42251
Filter Assembly
5
209-01-42260
Element Assembly
6
07000-F2065
O-Ring
7
01011-81000
Bolt
8
01643-31032
Washer
9
418-62-35111
Elbow
10
07002-21823
O-Ring
11
02896-21012
O-Ring
12
21S-62-31461
Union
13
07002-21423
O-Ring
14
02896-21009
O-Ring
15
209-01-42311
Union
16
02896-21012
O-Ring
17
07002-21423
O-Ring
18
02762-00405
Hose, Face Seal Type
19
02763-00311
Hose, Face Seal Type
20
04434-51612
Clip
21
01010-81225
Bolt
22
01643-31232
Washer
23
02762-00409
Hose, Face Seal Type
24
22S-62-14450
Bracket
25
01010-81225
Bolt
26
01643-31232
Washer
27
04434-51912
Clip
28
01010-81225
Bolt
29
01643-31232
Washer
30
203-62-61410
Joint
31
07002-22434
O-Ring
32
21N-64-36720
Tee
33
02896-21015
O-Ring
34
07002-22434
O-Ring
35
02764-00506
Hose, Face Seal Type
36
02762-00507
Hose, Face Seal Type
37
209-01-42281
Bracket
38
01010-81225
Bolt
39
01643-31232
Washer
40
07283-32738
Clip, Pipe
41
01597-01009
Nut
42
01643-31032
Washer
43
04434-52312
Clip
44
01010-81225
Bolt
45
01643-31232
Washer
46
209-01-42270
Bracket
47
01010-81225
Bolt
48
01643-31232
Washer
49
04434-52312
Clip
50
01010-81225
Bolt
51
01643-31232
Washer
