СТАРТЕР

Запчасти Komatsu PC80MR-3 СТАРТЕР ДВИГАТЕЛЬ

Схема запчастей Komatsu PC80MR-3 - СТАРТЕР ДВИГАТЕЛЬ
31
1
17
16
29
14
13
30
20
15
19
7
23
5
25
23
22
8
18
6
24
9
21
11
12
10
2
A
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

\0

22E-01-11501

ASPIRATED ENGINE, ASSEMBLY

1

YM129940-77010

STARTER MOTOR

2

YM129940-77100

ARMATURE, ASSEMBLY

5

YM129940-77130

COIL, ASSEMBLY, FIELD

6

YM129940-77140

SCREW

7

YM129940-77150

O-RING

8

YM129940-77160

BRUSH (+)

9

YM129940-77170

COVER, REAR

10

YM129940-77180

HOLDER, BRUSH

11

YM129940-77190

BRUSH SPRING

12

YM129940-77200

BRUSH (-)

13

YM129940-77210

SWITCH ASSEMBLY, MAGNETIC

14

YM129940-77220

GEAR HOUSING

15

YM129940-77230

RETAINER

16

YM129940-77240

SHIFT LEVER SET

17

YM129940-77250

COVER, ASSEMBLY

18

YM129940-77260

BOLT

19

YM129940-77270

BOLT

20

YM129940-77280

SCREW

21

YM123900-77510

PINION, ASSEMBLY

22

YM123900-77520

CLUTCH, ASSEMBLY

23

YMX2240610100

BEARING, BALL

24

YM123900-77540

PINION AND SHAFT, ASSEMBLY

25

YM119131-77550

STOPPER

29

YM121254-77810

COVER

30

YM114371-79070

BOLT

31

YM26116-120252

BOLT
