/ / / / / / M- БОКОВ. КРЫШКА ЛЕВ. С DUSTЗАЩИТА COVER
Запчасти Komatsu PC88MR-8 M- БОКОВ. КРЫШКА ЛЕВ. С DUSTЗАЩИТА COVER ЧАСТИ КОРПУСА
41
42
50
40
33
31
54
32
34
33
32
30
29
37
36
44
43
39
35
19
51
38
26
28
27
56
47
23
8
52
24
53
55
15
20
14
49
6
48
9
3
46
9
9
45
5
22
25
13
21
18
10
11
7
12
1
2
4
11
16
17
1
22P-54-11511
COVER
2
22P-54-12850
COVER
3
22P-54-12681
STOPPER
4
20N-54-71440
HINGE
5
22P-54-12860
COVER
6
22P-54-12681
STOPPER
7
20N-54-71440
HINGE
8
22P-54-12531
SHEET, BONDED
9
21W-46-41530
SEAL
10
22B-46-24361
LOCK ASSEMBLY
11
08037-02512
GROMMET
12
01010-81245
BOLT
13
175-54-34170
WASHER
14
01010-81225
BOLT
15
01643-31232
WASHER
16
01010-81235
BOLT
17
01643-31232
WASHER
18
22P-54-11161
COVER
19
22P-54-12411
SHEET, BONDED
20
22P-54-12431
SEAL
21
01010-81245
BOLT
22
175-54-34170
WASHER
23
01010-81225
BOLT
24
01643-31232
WASHER
25
22P-54-12230
SEAL
26
22P-54-13110
COVER
27
22B-46-24180
SPRING
28
01023-10512
SCREW
29
20Y-54-29232
BAR
30
22P-54-11141
HINGE
31
203-54-62180
HINGE, WELDED
32
01010-81225
BOLT
33
01643-31232
WASHER
34
22P-54-11881
BRACKET
35
22P-54-11171
COVER
36
01010-81225
BOLT
37
01643-31232
WASHER
38
22B-46-24361
LOCK ASSEMBLY
39
21W-54-51580
CATCHER
40
22P-54-12810
BRACKET
41
01010-81225
BOLT
42
01643-31232
WASHER
43
20Y-54-11611
STOPPER
44
01580-11008
NUT
45
01010-81245
BOLT
46
175-54-34170
WASHER
47
22P-54-12181
BRACKET
48
01010-81245
BOLT
49
175-54-34170
WASHER
50
21W-54-51460
SHEET, BONDED
51
21W-54-51480
SHEET, BONDED
52
21W-54-51490
SHEET, BONDED
53
21W-54-51550
SHEET, BONDED
54
21W-54-51560
SHEET, BONDED
55
21W-54-51570
SHEET, BONDED
56
21W-54-51380
SEAL
