Запчасти Komatsu PC95-1 ЦИЛИНДР РУКОЯТИ РАБОЧЕЕ ОБОРУДОВАНИЕ
25
24
8
1
23
22
7
20
6
5
4
21
16
34
32
34
16
19
18
3
33
17
16
30
3
16
12
31
2
11
32
33
28
26
29
15
14
9
13
10
27
1
21D-61-12102
ARM CYLINDER, ASSY.
2
21D-61-12121
PISTON ROD
3
21D-09-32140
BUSHING
4
21D-09-13110
SCREW
5
21D-09-73700
SPRING WASHER
6
21D-61-12130
COVER
7
21D-61-12140
RING
8
21D-61-12150
CYLINDER HEAD
9
21D-61-12160
BUSHING
10
21D-61-12171
PISTON
11
21D-61-12211
NUT
12
01252-41025
SCREW
13
21D-09-86810
BALL
14
22E-62-11230
FLANGE
15
21D-61-12111
CYLINDER
\15
21D-61-12201
KIT, GASKET
16
GASKET
17
O-RING
18
RING
19
GASKET
20
O-RING
21
RING
22
GASKET
23
GASKET
24
O-RING
25
RING
26
RING
27
GASKET
28
21D-62-15750
FLANGE
29
21D-09-69870
O-RING
30
21D-62-15760
FLANGE
31
21D-09-69870
O-RING
32
01252-40830
SCREW
33
21D-09-73690
SPRING WASHER
34
21D-09-89140
FITTING
