Запчасти Komatsu PC95R-2 ТОПЛИВН. ЛИНИЯ ДВИГАТЕЛЬ
28
42
28
10
31
28
28
31
33
28
28
59
31
28
58
57
58
28
32
57
17
44
18
15
43
28
58
59
29
58
22
13
41
45
6
24
11
30
12
22
41
4
56
23
52
22
2
14
6
26
22
25
53
27
13
24
8
13
9
1
47
35
34
7
42
46
3
50
5
55
54
13
21
48
52
51
49
19
A
B
B
C
20
\0
21D-01-00021
ENGINE, ASSY.
1
YM119000-55600
FILTER
2
YM129470-55610
BODY
3
YM194180-51640
CLAMP
4
YM26106-100252
BOLT
5
YM26106-100142
BOLT
6
YM101304-59020
UNION
7
YM129957-59040
PIPE
8
YM129335-59090
PIPE L=500
9
YM119560-59110
PROTECTION
10
YM119560-59051
PIPE
11
YM129129-59510
PIPE
12
YM119560-59110
PROTECTION
13
YM124766-59050
CLAMP
14
YM121750-59890
COLLAR
15
YM103854-59191
BOLT, ASSY.
17
YM124060-59380
PLUG
18
YM22190-060002
WASHER
19
YM121855-59880
JOINT
20
YM121855-59880
JOINT
21
YM121250-49110
JOINT
22
YM22190-120002
GASKET
23
YM23857-060000
SCREW
24
YM124766-59050
CLAMP
25
YM129957-59050
PIPE
26
YM129957-59120
PROTECTION
27
YM105025-59750
PIPE
28
YM124066-59100
CLAMP
29
YM129495-59300
SCREW
30
YM129980-59530
JOINT
31
YM121250-59550
PIPE
32
YM124732-59562
PIPE
33
YM129150-59580
PLUG
34
YM121855-59880
JOINT
35
YM128300-59910
VALVE
41
YM22190-140002
GASKET
42
YM22190-140002
GASKET
43
YM22190-080002
GASKET
44
YM26106-080102
BOLT
45
YM120324-55750
WATER SEPARATOR
46
YM120324-55760
FILTER
47
YMX0582810173
GASKET
48
YMX0580121073
O-RING
49
YMX0311121522
BOLT
50
YMX0300120414
GASKET
51
YMX0313080110
BOLT
52
YMX0588080273
GASKET
53
YMX2740134001
COVER
54
YMX2540025002
TANK
56
YMX0314080110
PLUG
57
YM121750-59910
JOINT
58
YM22190-140002
GASKET
59
YM23857-080000
BOLT
|A
SEE FIG. 0420
|B
SEE FIG. 0431
|C
SEE FIG. 0440
